Electrical Characteristics | Technology | Lithium Iron Phosphate |
Nominal Voltage | 12.8V | |
Nominal Capacity | 2Ah±5%@0.2C | |
Energy | 25.6Wh | |
Cycle Life | 100% Depth of Discharge ~2000 cycles | |
Internal Resistance | 30mΩ | |
Self Discharge | <3% per month @25℃ | |
Charge | Charge mode | CC&CV(0.2C Constant current & 14.6V Constant [email protected]) |
Max. Charge Voltage | 14.5V | |
Standard Charge Current | 3A | |
Max.Charge Current | 7.5A | |
Discharge | Discharge Cut-off Voltage | 37.5V |
Standard Discharge Current | 7.5A | |
Max.Continuous Discharge Current | 15A | |
Pulse Current | / | |
Operating Condition | Storage Temperature | 0℃to45℃(32℉to113℉) |
Humidity | 60±25% | |
Charge Temperature | 0℃to 45℃(32℉to113℉) | |
Discharge Temperature | -20℃to 45℃(32℉to113℉) | |
Structure | Water Dust Resistance | IP55 |
Terminal | F8 | |
Carrying | / | |
Case and Cover | ABS | |
Dimension（L*W*H) | 113*69*85mm | |
Weight | Approx1.0Kg |
