Product number: 01BQ1159-01
Cell model：18650/3.7V/2.5Ah
Battery specification: 18650-4S8P/14.8V/20Ah
Nominal voltage：14.8V
Nominal capacity：20Ah
Charging voltage: 16.8V
Charging current: ≤4A
Discharging current: 4A
Instant discharging current: 5A
End-off voltage: 12.0V
Internal resistance: ≤250mΩ
Battery weight: 1.6Kg
Product dimension: 170*90*78mm（Max）
Charging temperature：0～45℃
Discharging temperature: -20～60 ℃
Storage temperature: -20～35 ℃
Battery case: blue PVC
Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection, overcurrent protection, etc.
Application: wireless monitor terminal, testing instrument, etc.
