●Battery Modular design, distributed cooling design, better temperature control
Our 20-feet Air-cooled cabinet C&I solar power storage systems feature a revolutionary Battery Modular design and distributed cooling system. This means better temperature control, ensuring your batteries last longer and perform at their peak. No more worrying about overheating or costly replacements!
●Configuration of flammable gas detection, early warning system safety status
With our cutting-edge flammable gas detection and early warning system, you can rest easy knowing that safety is our top priority. Our 20-feet Air-cooled cabinet C&I solar power storage systems are equipped with advanced technology to constantly monitor safety status, giving you peace of mind and preventing potential hazards.
●System running data analysis, intelligent terminal display
Our 20-feet Air-cooled cabinet C&I solar power storage systems go beyond just storing energy – they also provide invaluable data analysis. Our intelligent terminal display gives you access to a comprehensive system running data analysis. Harness this information to optimize energy usage, make smarter decisions, and maximize your savings.
Battery parameters
| Battery type | 3.2V/280Ah |
| System battery configuration | 1P224S*5 |
| attery rated capacity | 1MWh |
| Battery voltage range | 627.2~ 806.4V |
| BMS communication interface | Ethernet |
| BMS communication protocol | Modbus TCPbus |
AC side parameters
| AC side power rating | 500kVA |
| AC current distortion rate | ＜3%(Rated power) |
| DC component | ＜0.5% |
| AC side rated voltage | 380V |
| Voltage range of power grid | 342~418V |
| Power factor | >0.99（Rated power） |
| Reactive power adjustable range | -105%~105% |
| Rated grid frequency | 50Hz |
| Power Grid frequency range | 45~55Hz |
| Isolation Mode | Transformer isolation |
System parameters
| Battery cabinet size（L*W*H） | L6058*W2591*H2438mm |
| Weight of container | 20T |
| Protection level | IP54 |
| Operating temperature range | (-30°C~50°C）(＞45°CReduction) |
| Operating humidity range | 0~95%（No condensation） |
| Battery temperature control mode | Intelligent air-cooled |
| Cooling mode of converter | Temperature control forced air cooling |
| Fire ?ghting system (battery container) | Aerosol, ?ammable gas detection+exhaust, water ?re(optional) |
| System communication interface | RS485、Ethernet、CAN |
| External system communication protocolal | Modbus TCP、Modbus RTU、CAN2.0 |
