Nominal voltage: 25.6V
Nominal capacity: 202Ah
Combination method (S series, P parallel): 8S1P
Size (mm): 520*442*177
Weight: 45kg
Combination: 8S1P 8S4P
Charging method: CC/CP/VP
Charging current: 0.2C (standard)
Maximum charging current: Maximum 1C @ 25℃
Charging cut-off voltage: 29.2V
Discharge method: CC/CP/VP
Discharge current: 0.5C
Maximum discharge current: Maximum 1C @ 25℃
Discharge cut-off voltage: 21.6V
Internal resistance: ≤50mΩ
Display: LCD
Communication interface: 485/232/CAN
Charging working temperature: charging: 0~ + 50°C
Discharge working temperature: Discharge: -20- + 55°C
Warranty period: 36~60 months
Scope of application: hospitals, bank data centers, rack-mounted homes, small and medium-sized enterprises, energy storage, backup power, wind and solar hybrid systems, offices, base stations, and other UPS energy storage power supplies.
Features: The front panel and BMS communication protocol can be customized and support parallel expansion; a variety of specifications and sizes are available for selection, convenient and quick installation, and simple connection.
