No | Item | Specifications | Remark |
1 | Nominal Capacity | 48Ah±5% | 0.2C5A discharge at 25℃ |
2 | Nominal Voltage | 24V | OCV |
3 | Charge Current | Standard：9.6A；Max：24A | Working temperature:0～45℃ |
4 | Charge cut-off Voltage | 29.2V | CC/CV |
5 | Discharge Current | Standard：24A ；Max：48A | Working temperature:-20~60℃ |
6 | Discharge cut-off Voltage | 20V | Not including cycle life,-10℃discharge |
7 | Pack Voltage | 26.62V~26.7V | Shipment status |
8 | Pack Impedance | ≤50 mΩ | 50% SOC at 25℃ |
9 | Weight | Approx: 12.5 kg | ABS Case |
10 | Dimension | 230*113*293（Not included Terminal） | Approx |
