Model | G8K-P3LA | G10K-P3LA | G12K-P3LA | |
DC data | ||||
Maximum PV Input power | 10.4KW | 13KW | 15.6KW | |
Maximum DC voltage | 800V | |||
Starting voltage | 160V | |||
Rated voltage | 550V（160~800V） | |||
MPPT operating voltage range | 200V ~650V | |||
Number of MPPTs | 2 | |||
Max. Input current of each MPPT | 13A+13A | 26A+13A | ||
Max. short-circuit current of each MPPT | 17A+17A | 34A+17A | ||
Battery data | ||||
Battery type | Lithium-ion battery / Lead-acid battery | |||
Operating voltage range | 40V~60V | |||
Max. charge and discharge current | 160A/160A | 200A/200A | 240A/240A | |
Exchange data | ||||
Rated power | 8KW | 10KW | 12KW | |
Max. apparent power | 8800VA | 11000VA | 13200VA | |
Rated voltage | 220/380Vac,230/400Vac (Three-phase) | |||
Rated frequency | 50Hz/60Hz | |||
Max. output current | 45A | |||
Power factor | 0.8 Leading~0.8 lagging | |||
Common data | ||||
Dimensions | 422*702*281 mm | |||
Weight | 37.5kg | |||
IP protection level | IP65 | |||
Range of working temperature | -40-60℃,>45℃ derating | |||
Relative humidity | 10-90% | |||
Maximum working altitude | 2000m | |||
Cooling method | Smart cooling | |||
