? No fires, no explosions
? Cycle life of?12500 times
? Energy efficiency of 97%
? Qualified seawater immersion test
Item | Parameter |
Dimensions (thickness * width * height) | 71.5*174.1*207.2 mm, excluding electrode poles |
Nominal voltage | 3.2V |
Internal resistance | ≤0.25mΩ |
Weight | 5.94±0.3kg |
Rated Capacity | 325Ah |
Energy efficiency | 97% |
Mass energy density | ≥175Wh/kg |
Volume energy density | 407Wh/L |
Voltage operating range | 2.5~3.65V |
Cycle life | 0.5P charge and discharge cycle?of?12500 weeks and capacity retention rate≥70% |
