Features
Multiple operating modes, off-grid and UPS, MPPT charger built-in.
Compatible with almost all 48V LiFePO4 battery pack.
Integrated smart APP, can remotely diagnose and update.
Max. 6pcs in parallel (Only OH5000TL).
Suitable for customizing various PV Energy Storage System.
Automatic activation of LiFePO4 battery pack.
| Technical Parameters / Model | OH3600TL | OH5000TL | OH5500TL | Configurable |
| Inverter output | ||||
| Rated Output Power | 3600W | 5000W | 5500W | |
| Max. Peak Power | 7200W | 10000W | 11000W | |
| Rated Output Voltage | 230Vac (Single Phase) | √ | ||
| Rated Output Frequency | 50/60Hz | √ | ||
| Battery | ||||
| Battery Type | Lithium-Ion Battery/Lead-Acid Battery/User-Defined | √ | ||
| Rated Battery Voltage | 24Vdc | 48Vdc | ||
| Max. PV MPPT Charging Current | 100A | 80A | 100A | √ |
| Max. AC/Generator Charging Current | 100A | 80A | 80A | √ |
| Maximum Hybrid Charging Current | 100A | 80A | 100A | √ |
| PV Input | ||||
| MPPT Number | 1 | |||
| Maximum Photovoltaic Input Power | 5000W | 6000W | ||
| Maximum Input Current | 18A | 27A | ||
| Max. PV Open Circuit Voltage | 500Vdc | |||
| MPPT Voltage Range | 40~450Vdc | 120~430Vdc | ||
| Mains/Generator Input | ||||
| Input Voltage Range | 170~264V | √ | ||
| Frequency Range | 50/60Hz | |||
| Bypass Over-Load Current | 20A | 40A | ||
| General Parameters | ||||
| Size (W*H*T mm) | 284*417*92 mm | 300*485*120 mm | ||
| Weight | 8.5kg | 9.5kg | ||
| Protection Level | IP20 | |||
| Range Of Working Temperature | -10~50℃, Derating>40℃ | |||
| Noise | <60dB | |||
| Cooling Method | Intelligent Air Cooling | |||
| Certification | EN IEC 61000-6-3:2021 / EN IEC 61000-6-1:2019 / EN 62920:2017+A1:2021 EN IEC 61000-3-2:2019 / A1:2021 / EN 61000-3-3:2013 / A2:2021 | |||
