Summary
The 3.6KW High-Frequency PV Inverter Off-Grid Solar Energy System from GOTERPOWER is a high-performance, 48VDC battery-compatible solution designed for residential and small-scale commercial use. Featuring a 98% conversion efficiency, this inverter ensures maximum energy utilization and cost savings. With a compact and lightweight design (6.8kg, 275*326*95mm), it supports single-phase output (220-240VAC, 60A) and offers reliable power supply in off-grid scenarios. Ideal for hybrid solar systems, this inverter supports two-way MPPT for optimized solar charging and stable power output. Built to operate in diverse environments (-15°C to 60°C, 20%-95% humidity), it ensures durability and performance. Perfect for residential energy storage, remote power supply, and backup systems, this inverter delivers clean, sustainable energy for a greener future.More
Specifications
Application:
Hybrid Solar System
Output Power:
3.5KW
  • 3.6KW High Frequency PV Inverter Off-Grid Solar Energy System 48VDC Battery for Home Use GOTERPOWER
  • 3.6KW High Frequency PV Inverter Off-Grid Solar Energy System 48VDC Battery for Home Use GOTERPOWER
  • 3.6KW High Frequency PV Inverter Off-Grid Solar Energy System 48VDC Battery for Home Use GOTERPOWER
  • 3.6KW High Frequency PV Inverter Off-Grid Solar Energy System 48VDC Battery for Home Use GOTERPOWER

Key attributes

Output Type
Single Phase
Inverter Efficiency
98%
Place of Origin
Guangdong, China
Model Number
SPI-3.6KW-24v
Brand Name
GOTERPOWER
Input Voltage
48V
Output Voltage
220-240VAC
Output Current
60A
Output Frequency
50/60(HZ)
Size
275*326*95(mm)
Type
DC/AC Inverters
Weight
6.8kg
Floating charging voltage
24Vdc
PV charging mode
Two way MPPT
PT Maximum input power
3600W
MPPT input voltage range
90 -500Vdc
Optimum Vmp operating range
300-400Vdc
Maximum PV input voltage
500Vdc
Operating environment humidity
20%-95%
Operating ambient temperature
-15-60*C
size
565*385*195(mm)

Packaging and delivery

Selling Units
Single item
Single package size
32.6X27.5X9.5 cm
Single gross weight
6.800 KG
