2–15 units can be used in parallel
Convenient to PLUG IN/OUT
6000 cycles life
Precise Battery Management Technology
High-density LiFePO4 battery, safer to use
Possess industry-leading BMS technology
Compatible with mainstream inverters
DOD 80%, extend battery life
| Basic Information | |
| Nominal Voltage | 48V DC |
| Voltage Range | 40.5V-54.75V |
| Nominal Capacity | 100Ah |
| Rated Capacity | 4.8kWh |
| Communication Protocol | CAN/RS485/RS232 |
| Max. Number Of Parallel Connections | 15 |
| Cycle Life | 6000 Cycles (@80% DoD) |
| Protection Mechanism | Temperature Protection/Over-Current Protection/Short-Circuit Protection Over-Charge Protection/Over-Discharge Protection/Low-Voltage Protection |
| Charging Parameters | |
| Recommended Charging Current | 50A |
| Max. Charging Current | 100A |
| Recommended Charging Voltage | 54V |
| Max. Charging Voltage | 54.75V |
| Discharging Parameters | |
| Recommended Discharging Current | 50A |
| Max. Discharging Current | 100A |
| Recommended Battery Discharge Cut-Off Voltage | 41.25V |
| Battery Cut-Off Voltage | 40.5V |
| Battery Recovery Voltage | 45V |
| General Parameters | |
| Dimension[W*D*H](mm) | 500*484*178mm |
| Gross/Net Weight | 44kg/41.5kg |
| Shell Material | Sheet Metal |
| Protection Rating | IP20 |
| Installation Method | Rack Mode |
| Cell Type | LiFePO4 |
| Certification & Safety Standard | |
| Safety Certification | CE |
| Transportation Safety Certification | UN38.3,Class9 |
| Temperature Parameters | |
| Discharging Temperature | -20~65°C |
| Charging Temperature | 0~55℃ |
| Storage Temperature | -20~45℃ |
