Nominal voltage: 51.2V
Nominal capacity: 200Ah
Size (mm): 480*442*177
Weight: 45kg
Combination method: 16S1P
Charging method: CC/CP/VP
Charging current: 0.2C (standard)
Maximum charging current: Maximum 1C @ 25℃
Charging cut-off voltage: 58.4V
Discharge method: CC/CP/VP
Discharge current: 0.5C
Maximum discharge current: Maximum 1C @ 25℃
Discharge cut-off voltage: 43.2V
Internal resistance: ≤50mΩ
Display: LCD
Communication interface: 485/232/CAN
Charging working temperature: charging: 0~ + 50°C
Discharge working temperature: Discharge: -20- + 55°C
Warranty period: 36~60 months
Scope of application: Rack-mounted backup power supply for homes, offices, base stations,small and medium-sized enterprises, wind and solar hybrid systems and UPS system ;
Features: The panel and BMS communication protocol can be customized and support parallel expansion; a variety of specifications and sizes are available for selection, convenient and quick installation, and simple connection
