| Items | Specifications |
| Nominal Voltage | 59.2V |
| Nominal Capacity | 15Ah |
| Cell inside | 18650 3.7V 2600mAh |
| Configuration | 16S6P |
| Standard Charge Current | 3A (0.2C) |
| Max. Charge Current | 15A (1C) |
| Protected Circuit Board(BMS) | BMS-Li16S3010-591 |
| Continue Discharge Current | 30A |
| Peak Discharge Current | 60A |
| Full Charged Voltage | 67.2V (4.2V per cell) |
| Charge Cut-off Voltage | 68V (4.25V per cell) |
| Discharge Cut-off Voltage | 40V (2.5V per cell) |
| Battery Net Weight | 5.22kg |
| Battery Dimension | 375*150*60mm |
| Connector | Input: a pair of 12AWG wires(20cm) with 30A fuse, XT60 connector a pair of 12AWG wires(50cm) with 30A fuse, XT60 connector |
| Output: a pair of 18AWG wires(20cm) with 2P 2.8mm connector | |
| Operating Temperature | Charging: 0°C ~ 45°C Discharging: -20°C ~ 55°C |
| Storage Temperature | (Recommended to store 20 ± 5°C for long term storage) |
| Life Cycle | >800 times (80% of initial capacity at 0.2C rate, IEC Standard) |
