Input voltage380V，-30%~+20%；208V，-10%~+20%Input frequency50Hz，±10%Connection mode3P3W/3P4W (compatible with both)Module capacity10A、20A、30A、40A、50A、75A、100A、150A、200ASingle cabinet capacity50A~1500AResponse time≤5msPower loss＜3%Harmonic compensation times2 to 61 timesCompensation rateNot less than 95%Compensation functionHarmonics, three-phase imbalance, reactive power, priority selectable.Compensation modeHarmonic full compensation, harmonic and imbalance, specific order compensation, harmonic source/reactive power source.CT scan requirements5A, sampling available on both the grid side and the load side.ProtectionMultiple protection functions such as overcurrent, overheating, over and under voltage protection.IP gradeModule: IP20, complete machine: IP30; higher IP grades for the complete machine can be customizedAmbient temperatureWorking temperature: -10°C ~ 50°C (derating above 40°C)Storage temperature: -25°C ~70℃Ambient humidity≤95% (45°C) no condensationAltitude<2000m; for altitudes over 2000 meters, use according to derating requirements specified in GB/T3859.2Incoming modeWhole cabinet: Top entry line/bottom entry line/through-busbar on top of the cabinetOverall dimensions10A（ibook）：243mm×167mm×88mm(2U)；10A~40A (High precision): 380mm x 400mm x 88mm (2U)；50A/75A：440mm×560mm×88mm(2U)；100A/150A：440mm×560mm×145mm(3.3U)；200A：440mm×560mm×228mm(5.2U)；Complete machine: 800 x 1000 x 2200; dimensions of the complete machine can beInstallation methodModule: rack-mounted or wall-mounted; complete machine: freestanding installationDisplay screen7-inch touch screenDisplay contentVoltage, load current, compensating current, grid-side current, voltage distortion rate, current distortion rateCommunication interface and communication modeRS485, LAN, WiFi (optional configuration)Communication protocolModbus Protocol
