Product Parameters
| Ac Side Parameters | |
| Rated Power (kW) | 1350 |
| Input Voltage(VAC) | 0.55/10/35 |
| Rated Frequency(Hz) | 50/60(±5%) |
| Power Factor | -0.99~0.99 |
| PCS Efficiency | 98% |
| Harmonic Current | ≤2% |
| Control Mode | P/Q mode, VSG mode, DC bus voltage control mode |
| Dc Side Parameters | |
| Cell Capacity(Ah) | 302 |
| Numbers in Parallel | 1 |
| Numbers in Series | 20 |
| Pack Combination | 1P20S |
| Pack Capacity(kWh) | 19.33 |
| Pack Series Quantity | 18 |
| Rack Combination | 1P360S |
| Rack DC Voltage Range(VDC) | 1008~1296 |
| Rack Capacity(kWh) | 347.90 |
| Rack Quantity | 2 |
| Container Quantity | 4 |
| Combination Of DC Side | 8P360S |
| Capacity Of DC Side（kWh） | 2783.2 |
| System Parameters | |
| Charge and Discharge Rate | ≤0.5C |
| Power/Capacity（kW/kWh） | 1350/2780 |
| Charge and Discharge Efficiency | ≥ 92% @0.5C（Excluding Auxiliary Power Consumption） |
| Working Temperature Range (℃) | -30~55 |
| Storage Temperature Range (℃) | -40~60 |
| Operating Humidity Range | <95%，without Condensation |
| Maximum Working Altitude （m） | ≤ 4000（>3000 Derating） |
| Cooling Method | Air Cooling |
| Fire Suppression System | Embedded |
| Other Parameters | |
| Weight(t) | ≤ 5.5 |
| Type | Modular Container |
| Size（Width * Height * Depth mm） | 1450×2896×2600 |
| IP Rating | IP54 |
