Modle | ALL IN ONE-105/215kWh | ALL IN ONE-125/257kWh |
| DC data | ||
| Battery type | LFP | |
Cell cycle life | 70% Retention with 8000 | 70% Retention with 10000 |
Battery cells | 3.2V/280Ah | 3.2V/314Ah |
Number of batteries in series and parallel | 1P240S | 1P256S |
Rated power | 215.04kWh | 257.23kWh |
Rated voltage | 768V | 819.2V |
Voltage range | 672V~876V | 716.8V~934.4V |
BMS communication port | RS485, Ethernet | |
Ac data | ||
Rated AC power | 105kW | 125kW |
Rated voltage | 400V | |
Ac rated current | 144A | 174A |
Output THDi | ＜3% | |
AC PF | 0.1~1 lead or lag (configurable) | |
Ac output | Three phase four wire+PE | |
Operation temperature | -20℃-50℃ | |
System parameter | ||
IP protection level | IP54 | |
Dimensions | 2007*1192*2301mm | |
Noise | ≥60dB | |
Fire fighting system | Aerosol, aerogel | |
Cooling method | Forced air cooling | |
Optional components | Perfluorohexane (replaceable aerosol), DC-DC connector block, UPS | |
Weight | ≤2.3T | ≤2.8T |
