A&S intelligent BMS is special designed for the varied Lithium battery packs. It gets functions of voltage collection, active current balance, overcharge and discharge over-current, temperature protection, Coulomb meter, Bluetooth, GPS remote, etc.
100% Incoming Material Inspection，100% in Line Testing，100% OQC Testing
A&S BMS has a supporting mobile app that supports Android and IOS operating systems. The app can be connected to the protection board through the Bluetooth of the mobile phone to view the working status of the battery.
Full capacity battery cell with accurately sorting and grading.
Active current balance, Coulomb meter, Bluetooth, GPS remote and etc.
Reach to more than 4,000 cycles at 80% DOD.
| Electrical Specifications | Temperature Parameters | ||
|---|---|---|---|
| Rated Capacity (0.5C,25°C) | 200 Ah | Operation Temperature Range | Charge: 32F to 131F/0C to 55C |
| Nominal Voltage | 25.6 V | Operation Temperature Range | Discharge:-4F to 140F/-20Cto 60C |
| Energy | 5120Wh | Storage Temperature Range | -13F to 149F/-25C to 65C |
| Cycle Life(0.5C/1C,25℃) | 5000 Cycles (80% DOD 80% EOL) | Operation Relative Humidity | 10%to 95% |
| Charging Parameters | Mechanical Specifications | ||
| Charge Voltage | 29.2V | Dimension(LxWxH) | 522*269*220mm/20.55*10.59*8.66in |
| Maximum Continuous Charge Current | 100 A | Weight | 28KG/61.72lb |
| Discharging Parameters | Terminal Bolt Size | M8 x 1.25 x 1.5 mm | |
| Maximum Continuous Discharge Current | 100A | Protection Rating | IP65 |
| Peak Discharge Current | 200A@3s | ||
| Certifications | Warranty | ||
| MSDS,UN38.3,FCC, PSE,CE,UKCA | YES | 1-year material Warranty | |
