A&S intelligent BMS is special designed for the varied Lithium battery packs. It gets functions of voltage collection, active current balance, overcharge and discharge over-current, temperature protection, Coulomb meter, Bluetooth, GPS remote, etc.
100% Incoming Material Inspection，100% in Line Testing，100% OQC Testing
A&S BMS has a supporting mobile app that supports Android and IOS operating systems. The app can be connected to the protection board through the Bluetooth of the mobile phone to view the working status of the battery.
Full capacity battery cell with accurately sorting and grading.
Active current balance, Coulomb meter, Bluetooth, GPS remote and etc.
Reach to more than 4,000 cycles at 80% DOD.
| Electrical Specifications | Temperature Parameters | ||
|---|---|---|---|
| Rated Capacity (0.5C,25°C) | 50AH | Operation Temperature Range | 50％ to 95％ |
| Nominal Voltage | 48.0V | Operation Temperature Range | 0℃ - 35℃ |
| Energy | 2400Wh | Storage Temperature Range | 0℃ - 25℃ |
| Cycle Life(0.5C/1C,25℃) | 5000 Cycles (80% DOD 80% EOL) | Operation Relative Humidity | 10％ to 90％ |
| Charging Parameters | Mechanical Specifications | ||
| Charge Voltage | 54.75V | Dimension(LxWxH) | 482*410*98mm/18.97*16.14*3.85in |
| Maximum Continuous Charge Current | 100 A | Weight | 23.5KG/51.5lb |
| Discharging Parameters | Terminal Bolt Size | ||
| Maximum Continuous Discharge Current | 100A | Protection Rating | IP20 |
| Peak Discharge Current | 150A@3S | ||
| Certifications | Warranty | ||
| MSDS,UN38.3,FCC, PSE,CE,UKCA | YES | 1-year material Warranty | |
