Full capacity battery cell with accurately sorting and grading.
Active current balance, Coulomb meter, Bluetooth, GPS remote and etc.
Reach to more than 4,000 cycles at 80% DOD.
| Electrical Specifications | Temperature Parameters | ||
|---|---|---|---|
| Rated Capacity (0.5C,25°C) | 100 Ah | Operation Temperature Range | 50％ to 95％ |
| Nominal Voltage | 48.0 V | Operation Temperature Range | 0℃ - 35℃ |
| Energy | 4800Wh | Storage Temperature Range | 0℃ - 25℃ |
| Cycle Life(0.5C/1C,25℃) | 5000 Cycles (80% DOD 80% EOL) | Operation Relative Humidity | 10% to 95% |
| Charging Parameters | Mechanical Specifications | ||
| Charge Voltage | 54.75V | Dimension(LxWxH) | 482*410*132mm/189.7*161.4*51.9in |
| Maximum Continuous Charge Current | 100 A | Weight | 36.5KG/80.46lb |
| Discharging Parameters | Terminal Bolt Size | ||
| Maximum Continuous Discharge Current | 100A | Protection Rating | IP20 |
| Peak Discharge Current | 150A@3S | ||
| Certifications | Warranty | ||
| MSDS,UN38.3,FCC, PSE,CE,UKCA | YES | 1-year material Warranty | |
