Start & Off Switches: The sddejin Battery Pack 51.2V206AH boasts a user-friendly control panel equipped with start and off switches, allowing for seamless power management. These switches ensure that you have complete control over the battery's operation, facilitating safe and efficient energy utilization.
Buzzer Alarm: For added safety and convenience, the battery system buzzer alarm that alerts users to any potential issues or system status changes. This feature enhances operational safety and minimizes the risk of unexpected downtime.
Reserved Display Interface: The inclusion of a reserved display interface offers the potential for future integration with advanced monitoring systems. This forward-thinking design ensures that the battery pack remains compatible with evolving technologies, enhancing its longevity and value.
REMA320A Charging Plug-in: The charging end of the sd Battery Pack 51.2V206AH utilizes the REMA320A plug-in, renowned for its reliability and compatibility with a wide range of charging sources. This ensures efficient and secure charging, minimizing downtime and maximizing battery life.
Anderson 350A Discharge Plug-in: The discharge end features the Anderson 350A plug-in, a heavy-duty connector renowned for its high current carrying capacity and durability. This allows for seamless integration with high-powered devices reliable power delivery under even the most demanding conditions.
Crafted with precision and attention to detail, the sddejin Battery Pack 51.2V206AH is designed to withstand the rigors of daily use in diverse environments. Its robust construction and high-quality components ensure long-lasting performance and reliability, making it the ideal choice for professionals who demand the very best.
| Item | Parameter | |
| Battery system | Battery type | Lithiumiron phosphate batteny |
| Group mode of battery system | 1P16S (two 1P8S modules in series) | |
| Rated voltage of battery system (V) | 51.2 | |
| Rated capacity of battery system (Ah) | 206 | |
| Total capacityof battery system (kwh) | 20.5 | |
| Total weight of battery system (Kg) | 165士4Kg | |
| Battery system voltage range (V) | 40-58.4 | |
| Maximum continuous discharge current (A) | 206A | |
| Maximum continuous charging current (A) | 200A | |
| Recommended SOC scope of work | 30-90% | |
| Cooling mode of battery system | natural cooling | |
| Protection level of battery system | IP54 | |
| Overall dimension of battery system (mm) | (800士10)*(530士5)* (310±5) |
|
| Operating temperature range | Charging0~55°C discharging-20~60°C |
|
| Cycle life | 2000times25°C(1C/1C) | |
| Note: Battery system with start switch, shutdown switch, buzzer, reserved display interface: charging side using REMA320A plug-in: discharging side using Anderson 350A plug-in. | ||
