Core Features & Advantages:
- Advanced MPPT Technology: At the heart of our controller lies the advanced Maximum Power Point Tracking (MPPT) technology. This innovative feature ensures an efficiency rating of no less than 99.5%, ensuring that your PV system is always operating at its peak performance, capturing every bit of available solar energy.
- High-Quality Components: Crafted with premium-grade components, the BAYKEE Solar Battery Charge Controller boasts a maximum conversion efficiency of up to8%. This exceptional performance enhances the overall system performance, maximizing your return on investment.
- Ultra-Fast MPPT Speed & Efficiency: Featuring an ultra-fast tracking speed, our controller swiftly identifies and locks onto the maximum power point, ensuring that energy conversion remains efficient and uninterrupted. The precision of this tracking ensures optimal performance under varying weather conditions.
- Accurate Peak Identification: With the ability to accurately identify the peak of the maximum power point, the BAYKEE controller guarantees that your PV system operates at potential, maximizing energy output.
- Automatic Power Limiting: To safeguard your system against overloading, the controller is equipped with a reliable function that automatically limits the power input from the PV array. This ensures stable and safe operation under all conditions.
- Wide Voltage Range Compatibility: Designed to accommodate a wide range of photovoltaic array maximum power point voltages, our controller offers unparalleled flexibility and compatibility with various PV systems.
- LCD Display & Dynamic Data Monitoring: The integrated LCD display provides a dynamic view of operating data and system status, allowing for easy monitoring and troubleshooting. This feature simplifies system management and enhances user experience.
- Battery Temperature Compensation: To maintain optimal charging performance, the controller incorporates a battery temperature compensation function. This intelligent feature adjusts charging parameters based on battery temperature, ensuring longer battery life and improved system efficiency.
Technical Specifications:
| Model |
BK-MPPT-192V 50A |
BK-MPPT-192V 100A |
BK-MPPT-240V 50A |
BK-MPPT-240V 100A |
BK-MPPT-360V 50A |
BK-MPPT-360V 100A |
BK-MPPT-384V 50A |
BK-MPPT-384V 100A |
| Rated system voltage |
192VDC |
240VDC |
360VDC |
384VDC |
| Rated charging current |
50A |
100A |
50A |
100A |
50A |
100A |
50A |
100A |
| PV open circuit voltage input range |
300V~400V |
350V-480V |
500V-645V |
580V~680V |
| max power point voltage range |
240V~320V |
275V-384V |
415V-516V |
440V~544V |
| Recommend PV open circuit Voltage |
343V±10V |
400V±10V |
600V±10V |
625V±10V |
| Efficiency |
≥98% |
| Empty loss |
≤5W |
| Temperature compensation algorithm |
-2mV/℃/2V |
| Communication |
RS485 |
| ambient working temperature range |
0℃～+40℃（Reduce power usage beyond temperature range） |
| Storage temp. Range |
-15℃～+50℃ |
| Altitude |
≤95%，no condensation |
| relative humidity |
≤4000m,（For power reduction above 2000m, it will be reduced by 2% every 100m.） |
| IP level |
IP20 |
| Measurement DxWxH |
393*203*507 |
| mounting hole size |
370*309 |
| Installation hole radius |
M6 |
| N.G(kg) |
20 |
23 |
21 |
24 |
21 |
24 |
21 |
24 |
