Main technical parameter
| Type | C45LE |
| Pole | 1P+N, 2P | 3P, 3P+N, 4P |
| Rated current (A) | 6,10,16,20,25,32,40,50,63 |
| Rated voltage (V) | 230 | 400 |
| Rated short circuit breaking capacity Icn(KA) | 6-32A:6/40-63:4.5 |
| Rated residual making/breaking capacity IAm(A) | 2000 |
| Rated residual action current IAn(A) | 0.03,0.05,0.1,0.3 |
| Rated residual non-action current IAno(A) | 30.5IΔn |
Applicable conducting wire
| Rated current(A) | 1-6A | 10A | 16，20A | 25A | 32A | 40，50A | 63A |
| Norminal cross section of wire mmp2 | 1 | 1.5 | 2.5 | 4 | 6 | 10 | 16 |
Residual current breaking time
| ln(A) | lΔn(A) | Breaking time(s) when equals to rating following |
| lΔn | 2lΔn | 5lΔn | 5,10,20,50,100,200,500a(A) | lΔtb |
| 6-63 | 0.03,0.05,0.1,0.3 | 0.1 | 0.06 | 0.04 | 0.04 | 0.04 |
The over-current protection property
| Ambient Temperature | Initial Status | Test Current | Expected Result | Expected Result | Note |
| 30± 2℃ | Cold position | 1.13ln | t≤1h | Non release | - |
| Carried out immediately after previous test | 1.45ln | t<1h | Release | - |
| Cold position | 2.55ln | 1s| Release | Current smoothly rises to specified value within 5s | |
| Cold position | 2.55ln | 1s32A) | Release |
| -5~+40℃ | Cold position | 3ln | t ≤0.1s | Non-release | Type B |
| Cold position | 5ln | t <0.1s | Release | Type B |
| Cold position | 5ln | t ≤0.1s | Non-release | Type C |
| Cold position | 10ln | t <0.1s | Release | Type C |
| Cold position | 10ln | t ≤0.1s | Non-release | Type D |
| Cold position | 20ln | t <0.1s | Release | Type D |
