| Basic Characteristics | Charging Power | 120 KW | 180 KW |
| Charging Cable | Standard 5 meter 250A Charge Cable | Standard 5 meter 250A Charge Cable |
| Charging Method | NFC + QR Code | NFC + QR Code |
| Network | 4G / LAN / WIFI | 4G / LAN / WIFI |
| Screen Size | 15-inch High Resolution | 15-inch High Resolution |
| Screen Resolution | 1024 × 768 PX | 1024 × 768 PX |
| Management System | NFC payment system and online management system | NFC payment system and online management system |
| Output | Double gun output | Product Type |
| Measurement | Internal DC electricity meter (accuracy 1%) | Internal DC electricity meter (accuracy 1%) |
| Product Specifications | Weight | Exterior Color | 450 kg |
| Exterior size | Standard size: 1750×615×740 mm or 1982×765×872 mm with selective Charging Gun | Standard size: 1750×615×740 mm or 1982×765×872 mm with selective Charging Gun |
| Exterior Type | DC Charger | DC Charger |
| Installation Method | Floor mounted | Floor mounted |
| Main material | Industrial-grade Alloy Casing | Industrial-grade Alloy Casing |
| Exterior color | White weatherproof spray | White weatherproof spray |
| Executive Standard | GB/T18487.1-2015 GB/T18487.2-2017 GB/T202341-2015 GB/T20234.3-2015 GB/T27930-2015 NB/T33001-2018 NB/T33008-2018 | GB/T18487.1-2015 GB/T18487.2-2017 GB/T202341-2015 GB/T20234.3-2015 GB/T27930-2015 NB/T33001-2018 NB/T33008-2018 |
| Application Environment | Applicable Site | Indoor / Outdoor | Indoor / Outdoor |
| Operating Temperature | -40℃~55℃ | -40℃~55℃ |
| Operating Humidity | <95%, non-condensing | <95%, non-condensing |
| Operating Altitude | ≤ 2000 m | ≤ 2000 m |
| Atmospheric Pressure | 80 kPa -110 kPa | 80 kPa -110 kPa |
| Input/output Specifications | Incoming Circuit Breaker | 250A | 400A |
| Output Voltage Range | 200-1000VDC | 200-1000VDC |
| Constant Power Voltage Output Range | 300-1000VDC | 300-1000VDC |
| Output Current | Single Charging Gun max 250A | Single Charging Gun max 250A |
| Input voltage | Three Phase 380VAC: 15% | Three Phase 380VAC: 15% |
| Input frequency | Unlock The Gun with the Power off | 50Hz + 1Hz |
| Safety | Protecting Class | IP54 | IP54 |
| Safety Protection | Overload Protection; Short-circuit Protection; Reverse Connection Protection; Ground Fault Protection; Flood Protection; Temperature Protection; Lightning Protection; Door Protection; Charging Gun Homing Detection; Smoke Protection; Fall Protection | Overload Protection; Short-circuit Protection; Reverse Connection Protection; Ground Fault Protection; Flood Protection; Temperature Protection; Lightning Protection; Door Protection; Charging Gun Homing Detection; Smoke Protection; Fall Protection |
| Other Features | Unlock The Gun with Power off | Support | Support |
| LED Indicator | Smart Charge Battery Level Indicator | Smart Charge Battery Level Indicator |
| Cable Management | Selective | Selective |
| Night Light | Include | Include |
| Charging Gun Electromagnetism Protection Lock | Include | Include |
| Occupied Fee | Include | Include |
