Summary
Ceramic Fiber Paper is a high-performance insulation material engineered for demanding industrial applications in the新能源 sector, including energy storage and battery systems. Designed to withstand extreme temperatures up to 1260℃, this asbestos-free ceramic fiber paper offers exceptional thermal shock resistance, low thermal conductivity, and high mechanical strength. Its flexibility, tear resistance, and ease of processing make it ideal for high-temperature sealing, heat insulation, and electrical thermal equipment protection. Widely used in industrial insulation, automotive thermal management, and electro-thermal components, this product ensures reliable safety and efficiency in critical systems.More
  • Ceramic Fiber Paper High Temperature Insulation Material for Industrial Sealing and Thermal Protection
  • Ceramic Fiber Paper High Temperature Insulation Material for Industrial Sealing and Thermal Protection
  • Ceramic Fiber Paper High Temperature Insulation Material for Industrial Sealing and Thermal Protection

Description:

Ceramic fiber paper uses ceramic fiber spraying cotton and is made through washing and adding bonding agent under vacuum condition. They have high intensity, good flexility and strong scissoring performance and the ideal material for producing high temperature washer, airproofing, heat insulation and insulation. Temperature level is 1050-1260℃.?


Ceramic fiber paper

Characteristics:

Low coefficient of heat-conduction ratio, low thermal capacity, Thermal shock resistance,
High quality of flexility and tear resistance. Not include asbestos, erosion resistance.

High quality of insulation and sound insulation.

Easiness of mechanical processing.

Tough texture and high quality of compression resistance.

Application rage:

Insulation, seal and safety materials for industrial need.

Insulation and heat insulation materials for electrica thermal equipments.

Insulation and heat insulation for equipments and electro thermal components.

Heat insulation materials for automobile.

Categorised temperature℃1260
Density of volume(kg/m3)170±15
Content of organic matter6-8
Coefficient that
heat conduct under
average temperature
200℃0.075-0.085
400℃0.115-0.121
600℃0.165-0.175
Main chemical
compositions (%)
AL2O347-49
AL2O3+SI2O398-99
Standard specification of the
prcducts
Thickness:0.5~6mmWidth:610/1220mmLength:20m~80m
The special specification can be made to order according to user's enquiry
