■Office and public place equipment, household systems, network transmission equipment, manufacturing, control systems, solar systems, oil fields, drilling field operations, etc.
■Small photovoltaic power generation systems such as homes, islands, ships, etc. provide stable, reliable and safe solutions.
| Product model: LS | 10212/24 | 20212/24/48 | 30224/48 | 40224/48 | 50248 | 60248 | |
| Rated Power | 1000W | 2000W | 3000W | 4000W | 5000W | 6000W | |
| Peak Power (20ms) | 3000W | 6000W | 9000W | 12000W | 15000W | 18000W | |
| Start The Motor | 1HP | 2HP | 3HP | 3HP | 4HP | 4HP | |
| Standard Battery Voltage | 12/24VDC | 12/24/48VDC | 24/48VDC | 24/48VDC | 48VDC | 48VDC | |
| Machine Size | 490*300*130 | 510*320*140 | |||||
| Package Size | 565*395*225 | 585*415*225 | |||||
| Net Weight | 11.5 | 17.5 | 19.5 | 21.5 | 23.5 | 25.5 | |
| Gross weight(carton packaging) | 13 | 19 | 21 | 23 | 25 | 27 | |
| Installation method | Wall-mounted | ||||||
| Enter | DC input voltage range | 10.5-15VDC(Single battery voltage) | |||||
| Mains input voltage range | 85VAC~138VAC/170VAC~275VAC | ||||||
| Mains input frequency range | 45Hz~65Hz | ||||||
| Maximum mains charging current | 25A/15A | 30A/25A/15A | 30A/20A | 30A/25A | 30A | 30A | |
| Mains charging method | Three-stage (Constant current, constant pressure, floating charge) | ||||||
| Output | Inverter output efficiency | ≥85% | |||||
| Inverter output voltage | 110VAC±2%/220VAC±2% | ||||||
| Inverter output frequency | 50/60Hz±1% | ||||||
| Inverter output waveform | Pure Sine Wave | ||||||
| Mains output efficiency | ≥99% | ||||||
| Mains output voltage range | 110VAC±10%/220VAC±10% | ||||||
| Mains output frequency range | Automatic Tracking | ||||||
| Inverter output waveform distortion | ≤3%(Linear load) | ||||||
| No-load loss in battery mode | ≤0.8%Rated Power | ||||||
| Mains mode no-load loss | ≤2%Rated Power (Mains charger does not work) | ||||||
| No-load loss in energy-saving mode | ≤10W | ||||||
| Type Of Battery (Optional) | Sealed lead acid battery | Charge Voltage:13V(Single Battery Voltage:24V:×2:48V:×4) | |||||
| Open lead acid battery | Charge Voltage:14V:float Voltage:13.8V(Single Battery Voltage:24V:×2:48V:×4) | ||||||
| lithium battery | Charge Voltage:14.2V:float Voltage:13.8V(Single Battery Voltage:24V:×2:48V:×4) | ||||||
| Custom battery | The charge and discharge parameters of different types of batteries can be customized according to user requirements | ||||||
| Protection | Battery undervoltage alarm | Lithium battery 9.5V (Single cell voltage) | |||||
| Battery undervoltage protection | Lithium battery 9V (Single cell voltage) | ||||||
| Battery overvoltage alarm | Lithium battery 14V (Single cell voltage) | ||||||
| Battery overvoltage protection | Lithium battery 15V (Single cell voltage) | ||||||
| Battery overvoltage recovery voltage | Lithium battery 13.5V (Single cell voltage) | ||||||
| Overload power protection | Automatic protection (battery mode), circuit breaker or insurance (Mains mode) | ||||||
| Inverter output short circuit protection | Automatic protection (battery mode), circuit breaker or insurance (Mains mode) | ||||||
| Temperature protection | ≤90℃(Turn off output) | ||||||
| Call The Police | A | Normal working state, no buzzer sound | |||||
| B | In the event of battery failure, abnormal voltage, and overload protection, the buzzer will beep 4 times per second | ||||||
| C | When the machine is normal when the machine is turned on for the first time, the buzzer will prompt 5 times | ||||||
| Built-in sun Energy controller (Optional) | Charging mode | PWM or MPPT | |||||
| Recharging Current | 10A/20A/30A/40A/50A/60A | ||||||
| PV input voltage range | 12V System:15V-44V;24V System:30V-44V;48V System:60V-88V | ||||||
| Maximum photovoltaic input voltage (under 25℃) | 12/24V System:50V;48V System:100V | ||||||
| Maximum photovoltaic input power | 12V System:140W/280W/420W/560W/700W/840W; 24V System:280W/560W/840W/1120W/1400W/1680W; 48V System:560W/1120W/1680W/2240W/2800W/3360W | ||||||
| Standby loss | ≤3W | ||||||
| Maximum conversion efficiency | ＞95% | ||||||
| Operating mode | Inverter priority/Mains priority/Energy saving mode | ||||||
| Conversion time | ≤4ms | ||||||
| Panel display | LCD | ||||||
| Cooling method | Smart fan control | ||||||
| Communication | Communication interface (Optional) | ||||||
| Operating temperature | -10℃~40℃ | ||||||
| Storage temperature | -15℃~60℃ | ||||||
| Noise | ≤55dB | ||||||
| Altitude | 2000m(Exceeding needs derating to use) | ||||||
| Relative humidity | 0%~95% No condensation | ||||||
| Warranty | 3 years | ||||||
| Remarks: 1. Specifications are subject to change without notice; 2. Special voltage and power requirements can be customized according to the actual situation of the user. | |||||||
