| Model | GB-S6K-EU | GB-S8K-EU | GB-S10K-EU | GB-S12K-EU | GB-S15K-EU | GB-S20K-EU | |
| Battery InputData | |||||||
| Battery Chemistry | Li-lon | ||||||
| Battery VoltageRange (V) | 150~700 | ||||||
| Max. Charging Current(A) | 37 | ||||||
| Max. Discharging Current (A) | 37 | ||||||
| Numberof battery input | 1 | ||||||
| Charging Strategy for Li-IonBttery | Self-adaption to BMS | ||||||
| PVString InputData | |||||||
| Max.DC Input Power(W) | 7800 | 10400 | 13000 | 15600 | 19500 | 26000 | |
| Max.DC InputVoltage(V) | 1000 | ||||||
| Start-up Voltage(V) | 150 | ||||||
| MPPT Range(V) | 150-850 | ||||||
| Full Load DC VoltageRange (V) | 195-850 | 260-850 | 325-850 | 340-850 | 423-850 | 500-850 | |
| RatedDC InputVoltage(V) | 600 | ||||||
| PV Input Current(A) | 20+20 | 26+20 | 26+26 | ||||
| Max. PV ISC(A) | 23+23 | 32+23 | 32+32 | ||||
| No.of MPP Trackers | 2 | ||||||
| No.of Strings per MPP Tracker | 1 | 2+1 | 2 | ||||
| AC Output Data | |||||||
| Rated AC Output and UPS Power(W) | 6000 | 8000 | 10000 | 12000 | 15000 | 20000 | |
| Max. AC Output Power(W) | 6600 | 8800 | 11000 | 13200 | 16500 | 22000 | |
| AC Output Rated Current(A) | 9.1 | 12.2 | 15.2 | 18.2 | 22.8 | 30.3 | |
| Max. AC Current(A) | 13 | 18 | 22 | 25 | 30 | 35 | |
| Max. Continuous AC Passthrough(A) | 80 | ||||||
| Peak Power (off grid) | 1.5 time of rated power, 10S | ||||||
| Generator input/Smart load/AC couple current(A) | 9.1 /80 /9.1 | 12.2 / 80 /12.2 | 15.2 / 80 /15.2 | 18.2 / 80 /18.2 | 22.8 / 80 /22.8 | 30.3 / 80 /30.3 | |
| Power Factor | 0.8 leading to 0.8 lagging | ||||||
| Output Frequency and Voltage | 50/60Hz; 3L/N/PE 220/380,230/400Vac | ||||||
| Grid Type | Three Phase | ||||||
| DC injection current (mA) | <0.5%1n | ||||||
| Efficiency | |||||||
| Max. Efficiency | 97.60% | ||||||
| Euro Efficiency | 97.00% | ||||||
| MPPTEfficiency | 99.90% | ||||||
| Protection | |||||||
| Integrated | PV Input Lightning Protection,Anti-islanding Protection,PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection,Surge protection | ||||||
| OutputOver VoltageProtection | DC Type II/AC Type III | ||||||
| Certifications and Standards | |||||||
| Grid Regulation | EN50549, AS4777.2:2015, VDE0126-1-1, IEC61727, VDEN4105-2018, G99 | ||||||
| Safety EMC /Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | ||||||
| GeneralData | |||||||
| Operating Temperature Range (℃) | -40~60℃, >45℃ derating | ||||||
| Cooling | Smart cooling | ||||||
| Communication with BMS | RS485;CAN | ||||||
| Warranty | 5 years | ||||||
| Model | GB-C20K-EU | ||||||
| Charger Module Data | |||||||
| Rate Power (kw) | 20.00% | ||||||
| Output Voltage Range (V) | 50~750 | ||||||
| Output Current Range (A) | 0~50 | ||||||
| Communication Port | CAN2.0 | ||||||
| Charging standard | CCS2 Type | ||||||
| Standards/regulations | IEC61851-1 | ||||||
| Operating Temperature Range (℃) | 40~60 | ||||||
| Cooling | Smart cooling | ||||||
| Warranty | 5 years | ||||||
| Certification | EN61851-1/EN61851-23 | ||||||
