| Product name: Diesel generator set | Model: CSC11 | Spec: 10KVA | ||||||
| Pro.ID: P00131 | Voltage： 3P 380v 50hz | Type： Silent | ||||||
Technical data table:
| NO. | Technical data | Parameter data | Remarks | |||||
| 1 | Standby Power | 11KVA | ||||||
| 2 | Prime Power | 10KVA | ||||||
| 3 | Standby Power | 9KW | ||||||
| 4 | Prime Power | 8KW | ||||||
| 5 | Dimension(LxWxH mm | 930*530*690 | ||||||
| 6 | Weight | 150kg | ||||||
Product configuration table:
| NO. | Part name | Brand | Model | Remarks | ||||
| 1 | Engine model | Yucai | 195F | |||||
| 2 | Alternator model | CSCPOWER | CSC8 | |||||
| 3 | Controller | CSCPOWER | ||||||
| 4 | Fuel tank | CSCPOWER | ||||||
| 5 | A high acoustic canopy | CSCPOWER | ||||||
| 6 | ATS（option） | CSCPOWER | ||||||
