Product Features:
|
MODEL |
EAHI-3000-SL |
EAHI-3600-SL |
EAHI-5000-SL |
EAHI-6000-SL |
|
PV INPUT |
||||
|
Max. input power |
4680W |
6500W |
7800W |
|
|
Max. input voltage |
550Vdc |
|||
|
Rated input voltage |
360Vdc |
|||
|
Start-up voltage |
100Vdc |
|||
|
Min. operating voltage |
150Vdc |
|||
|
MPPT voltage range |
100~540Vdc |
|||
|
Max. input current |
16A |
16A/16A |
||
|
Max. short-circuit current |
24A |
24A/24A |
||
|
Number of MPPT |
1 |
2 |
||
|
Number of input strings per MPPT |
1 |
1+1 |
||
|
BATTERY INPUT |
||||
|
Battery type |
Lithium-ion/Lead-acid battery |
|||
|
Voltage range |
42~58Vdc |
|||
|
Max. charge current |
66A |
75A |
100A |
100A |
|
Max. discharge current |
66A |
75A |
100A |
120A |
|
Charging curve |
3 Stages / Equalization |
|||
|
Lithium battery charging strategy |
BMS self-adaption |
|||
|
AC INPUT(Grid) |
||||
|
Grid type |
Single phase(L/N/PE) |
|||
|
Input voltage range |
184~276Vac |
|||
|
Input frequency range |
50±5Hz/60±5Hz |
|||
|
Max. input current |
21.8A |
26.2A |
36.5A |
40A |
|
AC OUTPUT(Grid) |
||||
|
Rated output power |
3000W |
3600W |
5000W |
6000W |
|
Max. apparent output power |
3000VA |
3600VA |
5000VA |
6000VA |
|
Grid system mode |
Single phase(L+N+PE) |
|||
|
Rated output voltage |
220Vac/230Vac |
|||
|
Rated output frequency |
50Hz/60Hz |
|||
|
Rated output current |
13.6A/13.0A |
16.4A/15.7A |
22.7A/21.8A |
27.3A/26.1A |
|
Max. output current |
13.6A |
16.4A |
22.7A |
27.3A |
|
Power factor |
>0.99 (0.8 leading ~ 0.8 lagging) |
|||
|
THDI |
≤3% (@ Rated Power) |
|||
|
AC OUTPUT(Back-up) |
||||
|
Rated output power |
3000W |
3600W |
5000W |
6000W |
|
Max. apparent power |
3000VA |
3600VA |
5000VA |
6000VA |
|
Output system mode |
Single phase(L+N+PE) |
|||
|
Rated output voltage |
230Vac (208/220/240Vac settable) |
|||
|
Rated output frequency |
50Hz/60Hz |
|||
|
Rated output current@230V |
13.0A |
15.7A |
21.8A |
26.1A |
|
Max. output current |
14.4A |
17.3A |
24.0A |
28.8A |
|
THDV |
≤3% (linear load) |
|||
|
Transfer time |
≤10ms |
|||
|
EFFICIENCY |
||||
|
Max. efficiency |
97.8% |
|||
|
MPPT efficiency |
99.9% |
|||
|
PROTECTIONS |
||||
|
Protections |
Over/under voltage, over/under-frequency, over load, output short-circuit, over temperature, residual current monitoring unit, output over-current, insulation resistance, anti islanding, surge protection |
|||
|
Output overvoltage protection |
DC Type II/AC Type III |
|||
|
OTHERS |
||||
| Communications | RS485, WIFI |
|||
|
Dimensions(W*H*D) |
548x440x197mm |
|||
|
Net weight |
21.4kg |
24.8kg |
||
|
Topology |
High frequency isolation(for battery) |
|||
|
IP rating |
IP66 |
|||
|
Operating temperature |
-25℃~+60℃ (>45℃ derating) |
|||
|
Cooling mode |
Natural cooling |
|||
|
Altitude |
4000m |
|||
|
Noise level at 1 m |
≤25dB |
|||
|
Installation mode |
Wall hanging |
|||
|
STANDARDS |
||||
|
Safety regulation |
IEC/EN 62109-1/-2, AS62109 |
|||
|
EMC |
EN 61000-6-1/-2/-3/-4 |
|||
|
Grid connection |
CEI 0-21, DIN VDE V 0124-100:2020, VDE-AR-N 4105:2018,AS4777.2, NRS097-2-1, EN 50549-1 |
|||
