| Model | CF48100T | CF48150T | |
| Connection method | 1P15S | 1P16S | 1P15S |
| Rated energy | 4800Wh | 5120Wh | 7200Wh |
| Rated capacity | 100Ah | 100Ah | 150Ah |
| Rated voltage | 48V | 51.2V | 51.2V |
| Voltage range | 42~52.5V | 43.2~56.8V | 43.2~56.8V |
| Charging current | 50A | 50A | 75A |
| Discharge current | 100A | 100A | 150A |
| Operating temperature | charge:0~50℃;discharge:- | 20~55℃;Storage:-30~45℃ | |
| Self-discharging rate | ≤3%(0~30℃/3 months) | ||
| Size(W*D*H) | 440*420*130mm | 440*525*130mm | |
| Weight | 41Kg | 43Kg | 56Kg |
Communication interface | RS485/RS232/CAN | ||
Chargingcurrent Limit function | With the function of automatically entering the current-limiting charging mode when detecting the battery cell:low voltage,high voltage,low temperature,high temperature,poor consistency,charging over-current protection | ||
Voltage acquisition accuracy | 0~5V,Detection accuracy≤10mV;0~60V Detection accuracy≤0.5% | ||
Current acquisition accuracy | Detection accuracy≤1%(0.5C charging/discharging) | ||
| Anti-theft function | Software anti-theft,communication anti-theft,gyroscope anti-theft and other functions are optional | ||
| Certification | IEC62619、IEC62620、UL1973、UL9540A、 UN38.3、ROHS、TLC、EMC | IEC62619、IEC62620、UL1973、 UN38.3、ROHS、EMC | |
