ESG Deep Cycle Off Grid Solar System Lithium Iron Phosphate Battery 48V 200AH Lithium Battery Module
. Long service life: product cycle times: 100% DOD6000 times
. The product has high safety, built-in temperature probe, safety alarm extinguisher, double protection function,
. BMS has the function of active equalization.
.It is intelligent and can detect voltage and electric quantity to avoid overcharge and overdischarge.
. All brands of inverter communication can be connected.
GRADE A QUALTY SOLUTIONS FOR GLOBAL NEW ENERGY APPLICATIONS
Overcharge protection function
Overdischarge protection function
Over current protection function
Short circuit protection function
Temperature protection function
Cell balance function
Communication function RS485, CANbus
Dual switch protection (On/Off switch, Master switch)
ESG Deep Cycle Off Grid Solar System Lithium Iron Phosphate Battery 48V 200AH Lithium Battery Module
| Seat vertical energy storage battery series -ES48200 | |
| Basic parameters: | |
| Batteries materials | Lithium iron phosphate |
| Series parallel mode (S series, P parallel) | 16S2P |
| Nominal voltage | 51.2V |
| Nominal capacity | 200Ah |
| Size(mm) | 565*195*700 |
| Weight | 90kg |
| Color | Optional |
| Parallel support | Parallel terminals are supported |
| Output port mode | terminal |
| Charging way | CC/CP/VP |
| Charging current | 0.2C(standard) |
| Maximum charging current | Max0.5C @25℃ |
| Charge cut-off voltage | 58.4V |
| Discharge way | CC/CP/VP |
| Discharge current | 0.5C |
| Maximum discharge current | Max0.6C @25℃ |
| Discharge cut-off voltage | 44.8V |
| According to | LCD |
| Communication interface | RS485/RS232/CAN |
| Charging operating temperature | charging:0~+50℃ |
| Discharge operating temperature | discharge:-20~+55℃ |
| The quality assurance period | 36 months |
| Scope of application | hospital, bank data center, wall-mounted home,enterprise energy storage backup power supply, wind complementary system,office, military, base station and other uninterrupted energy storage power supply. |
hospital, bank data center, base frame type home,
enterprise energy storage backup power supply, wind complementary
system, office, military, base station and other uninterrupted energy
storage power supply.
