Solar Panel Technical Parameters:
(wind solar hybrid) Controller Technical Parameters:
| Type | ES-GT1.5KW | ES-GT2KW | ES-GT3KW |
| Wind turbine rated power | 1.5KW | 2KW | 3KW |
| Wind turbine Max. power | 3KW | 4KW | 6KW |
| Wind turbine rated voltage | AC220V | AC220V | AC220V |
| *Solar panels power (optional) | 300W | 600W | 900W |
| Function | Rectifier,control, DC output | ||
| Automatic protection function | Over voltage protection, network electric cut off protection, regulated supply output, arrester | ||
| Manual function | Manual brake, reset, emergency switch | ||
| Display mode | LCD | ||
| Display content | Wind turbine voltage, current, power; Solar voltage, current, power; DC output voltage, DC output current, DC output power, total power. | ||
| PWM constant voltage | ≥320dc | ≥320dc | ≥320dc |
| Wind turbine 3-phase dump load voltage | 350±5Vdc | 350±5Vdc | 350±5Vdc |
| Wind turbine 3-phase dump load time-lapse | 12-20 min | 12-20 min | 12-20 min |
| Solar panels fuse | 2A | 3A | 4A |
| PWM dump load fuse | 10A | 10A | 16A |
| Fuse of DC output | 16A | 16A | 20A |
| Work environment temperature | -30-60°C | ||
| Relative humidity | <90% No condensation | ||
| Noise (1m) | <40dB | ||
| Degree of protection | IP20 (Indoor) IP65 (Outdoors) | ||
| Cooling method | Forced air cooling | ||
| *Communication interface (optional) | RS485/USB/GPRS/WIFI/Ethernet | ||
| *Temperature compensation (optional) | -4mv/°C/2V,-35°C~+80°C,Accuracy:±1°C | ||
| Size of the controller (mm) | 510*360*240 | 510*360*240 | 510*360*240 |
| Weight of the controller | 15Kg | 17Kg | 17Kg |
| Size of the dump load (mm) | 410*360*120 | 410*360*120 | 400*410*250 |
| Weight of the dump load | 7Kg | 9Kg | 13Kg |
On grid wind turbine single phase inverter 3-5KW:
| On grid wind turbine inverter | ES3KTL | ES5KTL |
| Rated output power (AC) | 3KW | 5KW |
| Max. Output power (AC) | 3.3KW | 5.5KW |
| Input voltage rang (DC) | 0-450V | 0-450V |
| MPPT Voltage range (DC) | 100V-400V | 100V-400V |
| Max. Input current (DC) | 11.2A | 18.7A |
| Rated current | 10.2A | 17A |
| THD Current harmonic | <3%(At rated power) | |
| Power factor | >0.99 | |
| Max. efficiency | 98% | |
| Allowable grid voltage range (AC) | 110V/120V/220V (Single-phase)±20% | |
| Allowable grid frequency range | 50Hz/60Hz±10% | |
| Automatic operation conditions | DC input and power grid meet the requirements, the inverter operates automatically | |
| Restart time after power failure | 2min ( Adjustable) | |
| Function | wind turbine curve setting | |
| Automatic protection | Inverter part: Polarity reverse connection protection, short circuit protection, island effect protection, LVRT, overheat protection, overload protection, ground fault protection, etc | |
| Display | Touch screen | |
| Monitoring content | DC Input voltage, current, power; inverter output voltage,current ,power; Cumulative power generation; Grid voltage ,Current . | |
| Protection level | IP20(Indoor)IP65 (Outdoors) | |
| Telematics | RS485/USB/GPRS/WIFI/Ethernet (Optional) | |
| Environment | Operating amb. Temp. & Hum -10-60°C,<90% no condensation | |
| Noise (1m) | <40dB | |
| Refrigeration mode | Forced air cooling | |
| Size / weight | 450*275*770mm 39kg | 450*275*770mm 44kg |
