At the core of Globalfrey ESS lies its unwavering safety. The system has undergone rigorous testing to ensure it remains impervious to a range of potential hazards, including needle puncture, short circuit, high temperature exposure, extrusion, and drop tests. These stringent measures guarantee that under any unforeseen circumstances, the system remains steadfast, without the risk of fire or explosion. This level of safety is paramount for industries and businesses where the consequences of power failure or system malfunction could be catastrophic.
Globalfrey ESS boasts an impressive track record of reliability. With lifespan exceeding 20,000 hours and still operating smoothly with over 80% of its original capacity, this system is built to last. Furthermore, the product's failure rate over the past decade has been meticulously controlled below 3%, a testament to its robust design and meticulous quality control. Coupled with a customer satisfaction rate of 100%, it's clear that Globalfrey ESS is the go-to choice for businesses seeking a dependable energy storage solution.
Adhering to the highest standards of quality and safety, Globalfrey ESS is compliant with vehicle standards and UN38.3 MSDS regulations, among others. This ensures that the system not only meets but exceeds the expectations of the most discerning industries and regulatory bodies. With its robust certification and compliance framework, Globalfrey ESS offers a level of stability that businesses can rely on for years to come.
Efficiency and productivity are key drivers industrial or commercial operation. Globalfrey ESS maximizes these by allowing for up to 80% depth of discharge (DOD) during use, while recommending a full charge once a week. This intelligent energy management strategy not only ensures a continuous power supply but also theoretically extends the battery life by approximately 20%. This translates into significant cost savings and reduced downtime, allowing businesses to focus on their core operations without the worry of power interruptions.
Technical Specifications:| DC Parameters | |
|---|---|
| Cell Type | Lithium Iron Phosphate |
| Pack Configuration | 43.008kWh/1P48S |
| Battery System Configuration | 215.04kWh/1P240S |
| Battery Voltage Range | 672-864V |
| Number Of Temperature Checks | 14x5 |
| AC Parameters | |
|---|---|
| Rated Power | 100KW |
| Maximum Power | 110KW |
| AC Current Distortion Rate | <3% |
| Grid Voltage Range | 380VAC， ‑ 15%~+10% |
| Power Factor | -1 (Lead) ~1 (Lag) |
| Rated Grid Frequency | 49.5Hz |
| ADSL | Three-Phase Four-Wire |
| System Parameter | |
|---|---|
| Maximum System Efficiency | 91.60% |
| Charge-Discharge Rate | <=0.5C |
| Depth Of Discharge | 95%DOD |
| System Voltage Format | TN380V |
| Cycles Times | ＞7900 |
| Transfer Time Between Charge And Discharge | <200ms |
| Communication Interface | 485、Ethernet |
| IP Grade | IP65 |
| Cooling Mode | Liquid Cooling |
| Operating Temperature | -20°C~50°C |
| Relative Humidity | 5-95%RH, No Condensation |
| Noise | <80dB |
| Altitude | <=2000m |
| Fire Protection System | Aerosol + Perfluoro Acetophenone (Optional) |
| Dimension(W/D/H) | 1600mm*1400mm*2000mm |
