Product Advantage
The SolaX TRENE ESS features advanced liquid cooling technology that ensures optimal performance by maintaining cell temperature differences under 3°C. With a robust 314Ah LFP battery, it guarantees long-term reliability. Safety is a top priority, with a four-level fire protection system in place. Powered by intelligent energy management through the SolaXCloud, TRENE offers real-time monitoring and effortless operation, making it the perfect choice for C&I energy storage solutions.
Product Parameters
| Rated AC power | 125 kW |
| Rated AC voltage | 3 / N / PE, 220 / 380 V 3 / N / PE, 230 / 400 V |
| Rated AC frequency | 50 Hz / 60 Hz |
| Battery type | LFP / 314 Ah |
| Battery capacity | 22 ~ 60 V |
| Rated battery voltage | 832 V |
| Dimensions (W×D×H) | 1350 x 2355 x 1350 mm |
| Weight | 2810 kg |
| Operating temperature range | -30 ~ 55°C (>45℃ derating) |
| Max. operation altitude | 3000 m |
| Cooling concept | Liquid cooling |
| Ingress protection | IP55 |
