Model | GBP24V-100AH | GBP24V-200AH | |
Nominal volt（V） | 24 | ||
Nominal capacity（AH） | 100(2.5KWH) | 200(5KWH) | |
Working volt range (V) | 22.8-30 | ||
Recommend charging volt（V） | 28 | ||
Recommend discharging cutoff volt（V） | 23.2 | ||
Standard charging current(A) | 25 | 50 | |
Max. Constant charging current(A) | 50 | 100 | |
Standard discharging current（A） | 25 | 50 | |
Max. Discharging current（A） | 50 | 100 | |
Temperature（℃） | -30℃～60℃(Recommend 10℃～35℃) | ||
Allowable humidity range | 0～85% RH | ||
Storage temperature（℃） | -20℃～65℃(Recommend 10℃～35℃) | ||
Protection | IP20 | ||
Cooling method | Natural air cooling | ||
Maximum Dimension(W*D*H) mm | 483*500*175 | ||
Remark | 0.5C Discharge Max: 1C, 80% DOD | ||
Parallel function | 24v support at most support 20 packs in paralle use(Capacity is 100kwh) | ||
Net Weight | 30KG | 57KG | |
Battery Cell | A Grade Prismatic Cell | ||
Protection | Built-in Smart BMS | ||
