Specification
ELECTRICAL
| Nominal capacity | 5Ah |
| Min. Capacity | 4.8Ah |
| Cell Initial Impedance | ≤ 120mΩ |
| Cycle life | >2000 (at 0.2C discharge) |
| Normal Voltage | 25.2V |
| Initial Voltage | ≥19.6V |
MECHANICAL
| Battery pack Thickness max. | ≈180MM |
| Battery pack Width max. | ≈80MM |
| Battery pack Height max. | ≈45mm |
| Pack Impedance | ≤150mΩ |
| Cell type | ternary lithium battery |
TEMPERATURE
| Discharge Temperature | 0～ 60℃ |
| Charge Temperature | 5～ 50℃ |
| Limited Charge Voltage | 25.2V |
| Cut-off Voltage | 19.6V |
| Standard Charging Method | 0.2C CC current charge to 29.4V, then CV charge till current declines to 0.01C |
| Operating humidity Range | ≤ 90%RH |
HEATING ELEMENT
| Standard Charging Current | 0.2C |
| Standard Charging Time | 6~7 hours |
| Rapid Charging Current | 0.5C |
| Rapid Charging Time | about 3.5hours |
| Standard Discharging Current | 0.2C |
| Max. Discharging Current | 1C |
Applications
special equipment
robotics
Rail transportation
Internet of Things
Medical equipment
Energy storage backup
Security Communication
Exploration surveying and mapping
AGV/RGV
electric equipment
