| NO. | Item | General Parameter | Remark | |
| 1 | Cell Model | FREY -110AH | Single cell, 110Ah | |
| 2 | Single Cell Housing Material | Aluminum Alloy | ||
| 3 | Standard Capacity (0.3 CA) | 550Ah | Max Capacity: 550AH | |
| 4 | Nominal Voltage | 83.2V | Working Voltage: 3.20V | |
| 5 | Max Charging Voltage | 94.9V | Single Ave. Charging Voltage 3.65 V | |
| 6 | Cut-off Voltage | 71.5 V | (Single Ave. Discharge Voltage 2.75 V) | |
| 7 | Standard Charging Current | ≤200A | ||
| 8 | Charging Time | About 2.5 Hrs | ||
| 9 | Continuous Discharge Current | 200A | ||
| 10 | Peak Discharge Current | 400A | 20 seconds | |
| 11 | Battery Dimension | ≤948*815*585mm (L*W*H) | Color: | |
| 12 | Total Weight (approx.) | Approximately 1100 kg | ||
| 13 | Charging Method (CC/CV) | Standard Temperature | 0℃~45℃ | |
| Discharge Temperature | -20℃~55℃ | |||
| Storage Temperature Humidity | 20℃~45℃ 25％～65％ | Avoid direct sunlight | ||
| 14 | IP Class | IP54 | ||
| 15 | Rest Time | 6H | ||
| 16 | MODEL | 8FBJ35 | ||
| 17 | Optional Functions | Heating, Cold Storage, Fire Fighting etc | N/A | |
