Model |
Type 150 |
Type 250 |
Type 390 |
Type 590 |
|
Compatible pole piece size |
long50-150mm |
long120-250mm |
long200-390mm |
long350-590mm |
|
Compatible cell thickness |
5-20mm |
|||
|
Monolithic efficiency |
Double Station:≤0.4S/PCS |
Double Station:≤0.45S/PCS |
DOUBLE STATION: ≤0.5S/PCS |
DOUBLE STATION: ≤0.55S/PCS |
|
Closing time |
≤8S |
|||
|
Pole piece positioning method |
Standard mechanical type (CCD type optional). |
CCD type |
||
|
Alignment of the pole piece with the diaphragm |
≤±0.3mm |
|||
|
Alignment of adjacent pole pieces |
≤±0.2mm |
|||
|
The overall alignment of the pole piece |
≤±0.4mm |
|||
|
Dust removal method |
The top of the equipment is equipped with FFU, and the internal cleanliness of the equipment can reach 100,000 after dust removal by the industrial vacuum cleaner |
|||
|
CCD detects the alignment of the pole pieces of the lamination table |
Matching |
|||
|
Rate |
99.2% |
|||
|
Action |
98% |
|||
