Save footprint and on-site workload
Maximize Battery Longevity: smart liquid cooling system maintains the optimal performance of cells and PCS throughout their lifecycle
Reduce Auxiliary Power Consumption: thermal control strategies adapt to various conditions, enhancing energy efficiency and cutting costs
Early Safety Alerts: Digital modelling technologies enable AI analysis throughout the cell's lifecycle, providing early warnings for cell safety
Intelligent Safety Monitoring: A multi-dimensional sensing system tracks cell, electrical, and structural safety, ensuring active safety management
Comprehensive Protection: Multi-level electrical protection and fire suppression design enhance overall safety
Up to 5MWh Capacity: 34.5% increase in energy density
Efficient Design: Integrated battery pack, PDU, and string PCS reducing the commissioning time by over 4h
Flexible Installation: Single-side opening design optimizes space and saves O&M workload
Improved RTE: Precise battery state algorithm optimized battery rack operation for power scheduling, increasing the power station's round-trip efficiency (RTE) by 2%
Enhanced Discharge Capacity: Intelligent regulation of each battery rack's charge and discharge boosts the system's overall discharge capacity
Product | Liquid-cooling ESS |
Model | HSL3C721-05015 |
Battery Cell | LFP-314Ah |
Configuration | 12P416S |
Rated Energy (kWh) | 5015.96 |
Rated Voltage (V d.c.) | 1331.2 |
Rated Power (kW) | 2500 @25℃ |
Rated AC Power (kVA) | 2500 @25℃ |
Rated Frequency | 50Hz/60Hz |
Dimensions (W*D*H) | 6058*2438*2896mm |
Operating Temperature | -30~55°C (> 45℃ derating) |
Cooling Method | Smart Liquid Cooling |
Certifications | UN38.3, IEC61000, IEC62933-5-2, IEC62619, IEC60730, IEC63056, IEC62477, UL9540A, UL9540, UL1973, NFPA855 |
Product | Liquid-cooling ESS |
Model | HSL3C700-05015 |
Battery Cell | LFP-314Ah |
Rated Energy (kWh) | 5015.96 |
Rated Voltage (V d.c.) | 1331.2 |
Voltage Range (V d.c.) | 1206.4~1476.8 |
Rated Power (kW) | 2500 @25℃ |
Dimensions (W*D*H) | 6058*2438*2896mm |
Operating Temperature | -30~55°C (> 45℃ derating) |
Cooling Method | Smart Liquid Cooling |
Certifications | UN38.3, IEC61000, IEC62933-5-2, IEC62619, IEC60730, IEC63056, IEC62477, UL9540A, UL9540, UL1973, NFPA855 |
