High-Capacity Phase Conversion - Engineered for demanding applications, this 40KVA-rated online UPS combines three-phase power input with single-phase output in a low-frequency design. With ISO/CE certifications and 50/60Hz compatibility, the system provides professional-grade power protection with 1.0 power factor efficiency for industrial and commercial installations.
Key attributes
|
Model
|
AF1K/AF1KL
|
AF2K/AF2KL
|
AF3K/AF3KL
|
AF6K/AF6KL
|
AF10K/AF10KL
|
|||||
|
Capacity
|
1KVA/900W
|
2KVA/1.8KW
|
3KVA/2.7KW
|
6KVA/5.4KW
|
10KVA/9KW
|
|||||
|
Battery voltage
|
12V7AH*2/36VDC
|
12V7AH*4/72VDC
|
12V7AH*6/96VDC
|
12V7AH*16/192VDC
|
12V7AH*16/192VDC
|
|||||
|
Size, D'W'H(mm)
|
350×144×230
|
425×190×328
|
425×190×328
|
533×260×560
/425×190×328 |
533×260×560
|
|||||
|
Net weight(kg)
|
9 / 6
|
18.4 / 9
|
23.4 / 10
|
55 / 12.2
|
62 / 21
|
|||||
|
Input
|
|
|
|
|
|
|||||
|
Input voltage
|
90V-285Vac
|
|
|
120-275VAC
|
|
|||||
|
Frequency range
|
40Hz-70Hz
|
|
|
46-54Hzor 56-64Hz
|
|
|||||
|
Phase
|
Single phase with ground
|
|
|
|
|
|||||
|
Power facto
|
≥0.99@100%Load
|
|
|
|
|
|||||
|
Output
|
|
|
|
|
|
|||||
|
Output voltage
|
100/110/115/120/127VAC or 200/208/220/230/240VAC
|
|
|
208/220/230/240VAC
|
|
|||||
|
AC voltage regulation
|
±1%
|
|
|
|
|
|||||
|
Freguency range
(synchronize range) |
40~46Hz or 54~60Hz
|
|
|
46-54Hz or 56-64Hz
|
|
|||||
|
Frequency range(batt. mode)
|
50Hz±0.25Hz or 60Hz±0.3Hz
|
|
|
50Hz or 60Hz±0.1Hz
|
|
|||||
|
Current crest ratio
|
3:1
|
|
|
|
|
|||||
|
Output current
|
4.5A
|
9.1A
|
13.6A
|
27A
|
45A
|
|||||
|
Harmonic distortion
|
≤3%THD(Linearload)
≤6% THD(Non-linear load)
|
|
|
≤3%THD(Linearload)
≤5%THD(Non-linear lead)
|
|
|||||
|
Overload
|
105%±5%125%±59%load>150%±5%: after 300ms turn to bypass and alarm.
|
|
|
105%±5%bypass and alarm;125%±5%30sees turn to bypass and alarm;load>135%±5%: afte
300ms turn to bypass and alarm.
|
|
|||||
|
Transfertime / AC mode to batt.
mode |
Zero
|
|
|
|
|
|||||
|
Wayeform(batt. mod)
|
Pure Sine wave
|
|
|
|
|
|||||
|
Efficiency
|
|
|
|
|
|
|||||
|
Battery mode
|
0.85
|
|
|
0.92
|
0.92
|
|||||
|
Battery
|
|
|
|
|
|
|||||
|
Battery type
|
12V/7Ah/Depending on
applications
|
12V/7Ah/Deoendingon
applications
|
12V/7Ah/Dependingon
applications
|
12V/7Ah/Dependingon
applications
|
12V/7Ah/Dependingon
applications
|
|||||
|
Battery numbers
|
2 / 0
|
4 / 0
|
6 / 0
|
16 / 0
|
16 / 0
|
|||||
|
Recharge time
|
8 hours recover to 90% capacity
|
|
|
9 hours recover to 90% capacity
|
|
|||||
|
Charging current
|
1A / 6.5A
|
1A / 5.5A
|
1A / 5.5A
|
1A / 5.5A
|
1A / 5.5A
|
|||||
|
Environment
|
|
|
|
|
|
|||||
|
Operation humidity
|
20-90% RH @ 0-40℃ Non-condensing
|
|
|
0-95% RH @ 0-50℃
Non condensing
|
0-95% RH @ 0-40℃
Non-condensing
|
|||||
|
Noise level
|
Less than 50dBA@1Meter
|
|
|
Less than 55dBA@1Meter
|
Less than 58dBA@1Meter
|
|||||
|
Management
|
|
|
|
|
|
|||||
|
Smart RS-232
|
Supports Windows 2000/2003/XP/Vista/2008/7/8,Linux, Unix, and MAC
|
|
|
|
|
|||||
|
Optional SNMP
|
Power management from SNMP manager and web browser
|
|
|
|
|
|||||
