2001-06
| Explosion-proof mark | Exd IIC T6 Gb |
| Protection rate | IP66 |
| Working voltage | DC24V(DC18V~DC28V) |
| Monitoring current | ≤0.3mA(24V) |
| Alarm current | ≤1mA(24V) |
| Contact capacity | DC30V/0.1A |
| Addressing method | Electrical encoder |
| Addressing range | 1-200 |
| dimensions | 145mm×130mm×91mm |
| Wiring | Communication line: L1, L2 polarity-free; |
| Applied places | Suitable for petroleum, chemical related area with explosion-proof requirements (Zone I and Zone II) |
| Applied standard | GB 16806-2006,GB 3836.1-2010,GB 3836.2-2010 |
| Electrical interface | 2-M20 |
| Working temperature | -20～+60℃ |
| Relative humidity | ≤93%(40±2℃) |
| Weight | 1.6Kg |
