Product Features:
Differentiated Cell Types: -P39148100-53Ah**: Perfectly suited for high-voltage stacking requirements, providing a robust foundation for energy-intensive applications.
IFP54220118-150Ah: Engineered for small-scale industrial and commercial energy storage, ensuring seamless integration and reliable performance.
IFP54220118-100Ah: Featuring an ultra-low height design, it ideally fits into 2 pull-out type energy storage setups, expanding its applicability to wall-mounted household energy storage systems.
High Safety & Reliability: Backed by esteemed international certifications such as UL and IEC, our battery cells ensure the highest level of safety and reliability, minimizing risks and maximizing user confidence.
Broad Environmental Adaptability: Capable of withstanding temperatures ranging from -20°C to 65°C, the Kexin Lithium Battery Cell excels in diverse climatic conditions,interrupted performance across various geographies.
Excellent Storage Performance: Even under high-temperature conditions (60°C for 7 days), our cells maintain over 95% of their capacity, demonstrating exceptional durability and long-term storage capabilities.
Application Areas:
The Kexin Lithium Battery Cell finds its home in a wide array of applications, including:
|
Item |
IFP39148100-53Ah |
IFP5422078-100Ah |
IFP5422078-100H |
IFP54220118-150Ah |
|
|
Battery Type |
LFP |
LFP |
LFP |
LFP |
|
|
Dimension |
Height |
100±0.5 mm(Containing Terminal |
79±0.5 mm(Containing Terminal |
79±0.5 mmiContaining Terminal |
118±0.5 mm(Containing Terminal) |
|
Width |
148±0.5mm |
220±0.5mm |
220±0.5mm |
220±0.5mm |
|
|
Thickness |
39±0.5mm |
54±0.5mm |
54±0.5mm |
54±0.5mm
|
|
|
Battery Weight
|
1.10±0.15Kg
|
1.90±0.15Kg
|
1.90±0.15Kg
|
3.0±0.15Kg
|
|
|
AC Internal Resistance(AC 1KHz)
|
0.30~0.70mΩ
|
0.30～0.65mΩ
|
0.20～0.60mΩ
|
0.20～0.60mΩ
|
|
|
Rated Voltage
|
3.2V
|
3.2V
|
3.2V
|
3.2V
|
|
|
Rated Capacity
|
53Ah
|
100Ah
|
100Ah
|
150Ah
|
|
|
Standard Charge Method
|
CC-CV,0.5C,3.65V,2.65A Cut-Off
|
CC-CV,0.5C,3.65V,5A Cut-Off
|
CC-CV,0.5C,3.65V,5A Cut-Off
|
CC-CV,0.5C,3.65V,75ACut-Off
|
|
|
Charge
Current
|
Standard Charge
Current
|
26.5A
|
50A
|
50A
|
75A
|
|
Max.Charge Current
|
53A
|
100A
|
100A
|
150A
|
|
|
Discharge
|
Cut-off Voltage
|
T>0℃2.5V,T≤0℃2.0V
|
T>0℃2.5V,T≤0℃2.0V
|
T>0℃2.5V,T≤0℃2.0V
|
T>0℃2.5V,T≤0℃2.0V
|
|
Max.Continuous
Discharge Current |
53A
|
100A
|
100A
|
150A
|
|
|
Discharge Capacity
|
Standard Discharge (0.5C)
|
≥53Ah
|
≥100Ah
|
≥100Ah
|
≥150Ah
|
|
Multiplier Discharge (1C)
|
≥53Ah
|
≥100Ah
|
≥100Ah
|
≥150Ah
|
|
|
Cycling Life
|
≥6000 Times,0.5C/1C,25℃
|
≥3000 Times,0.5C/1C,25℃
|
≥6000Times,0.5C/1C,25℃
|
≥6000 Times,0.5C/1C,25℃
|
|
