ECO mode operation for energy saving (ECO)
Emergency power off function (EPO)
Generator compatible
SNMP+USB+RS-232 multiple communications
3-stage extendable charging design for optimized battery performance
Adjustable battery numbers for long-run model
Maintenance bypass available
Parallel operation with common battery
Power walk-in function
Optional isolation transformer offers full isolation and complete common mode noise rejection
| MODEL | KH33 III -30 KL | KH33 III -40KL | KH33 III -60 KL | KH33 III -100KL | KH33 III -120KL | KH33 III -180KL | KH33 III -200KL | |
|---|---|---|---|---|---|---|---|---|
| PHASE | 3-phase in/3-phase out | |||||||
| CAPACITY | 30KVA / 30KW | 40KVA/40KW | 60KVA / 60KW | 100KVA / 100KW | 120KVA / 120KW | 180KVA / 180KW | 200KVA / 200KW | |
| PARALLEL CAPABILITY | 4 | |||||||
| INPUT | ||||||||
| Nominal Voltage | 3 x 360/380/400/415 VAC (3Ph+N) | |||||||
| Voltage Range | 110-300 VAC @ 50% load ; 176-276 VAC @ 100% load | |||||||
| Frequency Range | 40~70 Hz | |||||||
| Power Factor | ≧ 0.99 @ 100% load | |||||||
| Harmonic Distortion (THDi) | < 4% at full linear load | |||||||
| OUTPUT | ||||||||
| Output Voltage | 3 x 360*/380*/400/415 VAC (3Ph+N) | |||||||
| AC Voltage Regulation (Batt. Mode) | ± 1% | |||||||
| Frequency Range (Synchronized Range) | 46~54Hz or 56~64Hz | |||||||
| Frequency Range (Batt. Mode) | 50/60 Hz ± 1% | |||||||
| Current Crest Ratio | 3:1 (max.) | |||||||
| Harmonic Distortion | ≦2% THD (Linear Load) ≦5% THD (Non-linear Load) | |||||||
| Transfer Time | AC mode to Battery mode | zero | ||||||
| Inverter to Bypass | zero | |||||||
| Wave Form (Batt. Mode) | Pure Sine Wave | |||||||
| Overload Capability | 100-110% for 60 min, 111-125% for 10 min, 126%~150% for 1 min; >150% immediately shutdown | |||||||
| BYPASS | ||||||||
| Nominal Voltage | 3 x 360/380/400/415 VAC (3Ph+N) | |||||||
| Voltage Range | 305VAC~457VAC | |||||||
| Frequency Range (Synchronized Range) | 46~54Hz or 56~64Hz | |||||||
| Overload Capability | > 130% 1 minute (default) Continously working until breaker protection (optional) | |||||||
| EFFICIENCY | ||||||||
| AC Mode | 95.5% | |||||||
| ECO Mode | 98.5% | |||||||
| Battery Mode | 94.5% | |||||||
| BATTERY | ||||||||
| Battery Type | Depending on application | |||||||
| Numbers | 32~40 pcs (Adjustable) | |||||||
| Charging Current (max.) | 1-12A, Adjustable | 1-18A, Adjustable | 2-36A, Adjustable | 3-54A, Adjustable | ||||
| Charging Voltage | +/-13.65V*N (N = 16~20) | |||||||
| INDICATORS | ||||||||
| Touch color LCD Panel | UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions | |||||||
| ALARM | ||||||||
| Battery Mode | Sounding every 4 seconds | |||||||
| Low Battery | Sounding every second | |||||||
| Overload | Sounding twice every second | |||||||
| Fault | Continuously sounding | |||||||
| PHYSICAL | ||||||||
| Dimension, D X W X H (mm) | 815 x 300 x 1000 | 815 x 300 x 1000 | 974 x 600 x 1600 | |||||
| Net Weight (kgs) | 74 | 54 | 87 | 250 | 250 | 340 | 345 | |
| ENVIRONMENT | ||||||||
| Operation Temperature | 0-40°C | |||||||
| Operation Humidity | <95% and non-condensing | |||||||
| Altitude** | 0 ~ 1000m at full load | |||||||
| Noise Level | Less than 65 dB @ 1 Meter | Less than 70 dB @ 1 Meter | Less than 75 dB @ 1 Meter | |||||
| MANAGEMENT | ||||||||
| Smart RS-232/USB | Supports Windows? 2000/2003/XP/Vista/2008, Windows? 7/8, Linux and MAC | |||||||
| Optional SNMP | Power management from SNMP manager and web browser | |||||||
| *When output voltage is set as 3 x 360VAC or 3 x 380VAC, the output power of the unit will be de-rated to 90%. | ||||||||
| **If the UPS is installed or used in a place where the altitude is higher than maximum height, the output power will be derated 1% per 100m. | ||||||||
| Product specifications are subject to change without further notice. | ||||||||
