True double-conversion
Microprocessor control optimizes reliability
Output power factor PF1.0
Wide input voltage range(110-300VAC)
Converter mode available
ECO mode for energy saving only available for 1-3KVA models
Generator compatible
Adjustable charging current via LCD or software(1A-6A) only available for 6K/10K models
Emergency power off function(EPO) only available for 6K/10K models
Comprehensive display allows easy monitoring access of UPS status
IP20 Rating
| Model | KR11 Plus-1K(L) | KR11 Plus-2K(L) | KR11 Plus-3K(L) | KR11-6K(L) | KR11-10K(L) | |
|---|---|---|---|---|---|---|
| Capacity | 1KVA/1000W | 2KVA/2000W | 3KVA/3000W | 6KVA/5400W | 10KVA/9000W | |
| Input | Nominal Voltage | 100/110/115/120/127VAC or 200/208/220/230/240VAC | 208/220/230/240VAC | |||
| Voltage Range | 55-145VAC or 110-300VAC at 50% load 85-140VAC or 160-280VAC at 100% load | 110-300VAC±3% at 50% load 176-300VAC±3% at 100% load | ||||
| Frequency | 40-60Hz / 50-70Hz | 40-60Hz/50-70Hz | ||||
| Power Factor | 0.99 | |||||
| Output | Voltage | 100/110/115/120/127VAC or 200/208/220/230/240VAC | 208/220/230/240VAC | |||
| Voltage Regulation | ±1% | |||||
| Frequency Range (Synchronized Range) | 47-53Hz or 57-63Hz | 46-54Hz or 56-64Hz | ||||
| Frequency Range (Batt. Mode) | 50Hz±0.25Hz or 60Hz±0.3Hz | 50Hz±0.1Hz or 60Hz±0.1Hz | ||||
| Current Crest Ratio | 3:1 | |||||
| Harmonic Distortion | ≤3% THD(Linear load) ≤6% THD(Non-linear load) | ≤3% THD(Linear load) ≤6% THD(Non-linear load) | ||||
| Transfer Time | 0ms | |||||
| Wave Form | Pure Sine Wave | |||||
| Efficiency | AC Mode | 88% | 89% | 90% | 89% | 90% |
| Battery Mode | 83% | 87% | 88% | 88% | 89% | |
| Battery (Standard Model) | Battery Type | 12V9AH | 12V9AH | 12V9AH | 12V7AH | 12V9AH |
| Numbers | 2PCS | 4PCS | 6PCS | 16PCS | 16PCS | |
| Typical Recharge Time | 3 hours recover to 90-100% capacity | 9 hours recover to 90% capacity | ||||
| Charging Current | 1A | Default:1.0 A ± 10%, Max.:2.0A ± 10% | ||||
| Charging Voltage | 27.4VDC ± 1% | 54.7 VDC ±1% | 82.1 VDC ±1% | 218.4 VDC ± 1% | ||
| Battery (Long-run Model) | Battery Type | Depending on the capacity of external batteries | ||||
| Numbers | 3 | 6 | 8 | 16-20** (adjustable) | ||
| Charging Current | 1.0A/2.0A/4.0A/6.0 A | Default:4.0 A ± 10%, Max.:6.0A ± 10% | ||||
| Charging Voltage | 41.0VDC ± 1% | 82.1 VDC ±1% | 109.4VDC ±1% | 273 VDC ± 1% (based on 20 pcs batteries) | ||
| Indicators | LCD Panel | UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions | ||||
| Alarm | Battery Mode | Sounding every 4 seconds | ||||
| Low Battery | Sounding every second | |||||
| Overload | Sounding twice every second | |||||
| Fault | Continuously sounding | |||||
| Physical(Standatd Model) | Dimension,D*W*H(mm) | 310*438*88(2U) | 410*438*88(2U) | 630*438*88 | UPS Unit:500*438*88(2U) Battery pack:668*438*88(2U) | UPS Unit:580*438*133(3U) Battery pack:668*438*88(2U) |
| Net Weight(kgs) | 12 | 19 | 29.3 | UPS Unit:15 Battery Pack:40 | UPS Unit:18 Battery Pack:48 | |
| Physical(Long-run Model) | Dimension,D*W*H(mm) | 310*438*88(2U) | 410*438*88(2U) | 500*438*88 (2U) | 580*438*133(3U) | |
| Net Weight(kgs) | 9 | 12 | 14.2 | 15 | 18 | |
| Environment | Humidity | 20-90 % RH @ 0- 40°C (non-condensing) | 0-95 % RH @ 0- 40°C (non-condensing) | |||
| Noise Level | Less than 50dBA @ 1 Meter | Less than 55dBA @ 1 Meter | Less than 58dBA @ 1 Meter | |||
| Management | Smart RS232/USB | Supports Windows 2000/2003/XP/Vista/2008/7/8, Linux, Unix, and MAC | ||||
| Optional SNMP | Power management from SNMP manager and web browser | |||||
| *Long-run model is only available in 200/208/220/230/240VAC systems and output is PF0.8. | ||||||
| **Derate to 80% of capacity in Frequency converter mode and to 80% when the output voltage is adjusted to 100/200/208VAC | ||||||
| * Product specifications are subject to change without further notice | ||||||
