| NO. | Items | Parameter | Remarks | |
| 1 | Nominal Capacity | 90Ah | Standard Discharge | |
| 2 | Minimal Capacity | 90Ah | Standard Discharge | |
| 3 | Work Voltage | 2.5~3.65V | ||
| 4 | Internal Resistance(Ac. 1kHz) | 0.1~0.5mΩ | Fresh Cell,30%SOC | |
| 5 | Charging Time | Standard Charge | ~4h | Reference Value |
| Fast Charge | ~1h | |||
| 6 | Recommended SOC Window | SOC :10%~90% | ||
| 7 | Operating Temperature | Charging Temperature | 0~45°C | Refer to section 4.2 |
| Discharging Temperature | -20~55°C | Refer to section 4.4 | ||
| 8 | Weight | 1.94kg | ||
LiFePo4 Battery Cell Feature & Advantages
1. Safety: safest Li-Ion battery, MSDS CE ROSH approved, built in PCM/PCB, none fire or explosive
2. Clean and Green energy, no toxic material contained
3. Powerful battery
4. Long life cycle, >3500 cycles
5. No memory effect,highly efficient charge anytime, no reduction of capacity
6. Operation temperature: -20~55°C
7. Portable design
8. Good performance at high temperature and high temperature resistance
9. Low self-discharge rate: < 3% monthly
LiFepo4 Battery Application
*Solar energy storage
*Industrial energy storage
*Residential energy storage
*Motive power [electric vehicles (EV)]
-Forklifts
-Semi-traction (sweepers and scrubbers)
-Buses, trams, and more
-AGV (automated guided vehicles)
-Personal mobility (wheelchair, electric bikes, and scooters)
-Starter battery for motorcycles
