Advantages:
Cycle Time 6000@80% DOD, 25℃，0.5C
Safe and Long Life Cycle(5 years warranty)
High Energy & Intelligent BMS
Intelligent BMS & Modular Design
Comprehensive compatibility
Specifications:
Model | CE-LBT-12300 |
Capacity | 3.8KWH |
Voltage | 12V |
Normal Voltage | 12.8V |
Normal Voltage Range | 12-14.4V |
Charge Cut-off Voltage | 28.8V |
Discharge Cut-off Voltage | 12V |
Max. Charge & Discharge Current | 150A |
Recommend Charge & Discharge Current | <100A |
| Normal Output Power | 1280W |
| Max. Output Power | 1920W |
Series & Parallel Connection Amount | Can be in series for 24/48V with 2/4 packsParallel 2-6 packs |
Ingress Protection | IP21 |
Cycle Times | 6000@80% DOD, 25°C, 0.5C |
Working Temperature | -10-60℃ |
| Product Dimension | 500×350×195mm |
| Package Dimension | 540×380×235mm |
