Voltage Range(V) | 448~552 | |
Cell | 3.2V50Ah | |
Series & Parallels | 160S2P | |
Rated Voltage(V) | 512 | |
Rated Capacity(Ah) | 100 | |
Rated Energy(KWh) | 51.2 | |
Maximum Charge Current(A) | 100 | |
Discharge cut-off Voltage(V) | 448 | |
Charge Voltage(V) | 544~552 | |
Cycle Life(@25℃,1C/1C,100%DOD) | >2500 | |
Short-circuit Current(＜10ms) | Approx.9000A | |
System Dimension(W* D* H) | (600*1000*2000 ) mm | |
Total Weight(Kg) | Approx.900 | |
Internal Resistance Fully Charged@ 25℃ | ≤60mOhms | |
