Model | VICTOR NMS-1000-12 | VICTOR NMS-1500-24 | ||
RATED POWER | 1000W/1000VA | 1500W/ 1500VA | ||
AC Input | ||||
Voltage | 230VAC | |||
Selectable Voltage Range | 170-280VAC(For Personal Computers) | |||
90-280VAC(For Home Appliances) | ||||
Frequency Range | 50 Hz/60Hz(Auto sensing) | |||
AC OUTPUT | ||||
AC Voltage Regulation | 230VAC土5% | |||
Surge Power | 2000VA | 3000VA | ||
Efficiency(Peak)PV to INV | 98% | |||
Efficiency(Peak)Battery to INV | 94% | |||
Transfer Time | 10ms | |||
BATTERY | ||||
Battery Voltage | 12VDC | 24VDC | ||
Floating Charge Voltage | 13.5VDC | 27VDC | ||
Overcharge Protection | 16VDC | 32VDC | ||
SOLAR CHARGER & AC CHARGER | ||||
Solar Charger Type | MPPT | |||
Maximum PV Array Power | 600W | 1200W | ||
MPPT Range @ Operating Voltage | 20~150VDC | 30~150VDC | ||
Maximum PV Array Open Circuit Voltage solar | 150VDC | |||
Maximum Solar Charging Current | 40A | |||
Maximum AC Charging Current | 40A | |||
Maximum Solar+AC Charging Current | 80A | |||
PHYSICAL | ||||
Dimension,D*W*H(mm) | 290*240*91 | |||
Carton Dimension,D *W *H(mm) | 340*295*145 | |||
Net Weight(kgs) | 3.5 | 3.6 | ||
Gross Weight(kgs) | 4.0 | 4.2 | ||
ENVIRONMENT | ||||
Humidity | 5% to 95% Relative Humidity(Non - condensing) | |||
Operating Temperature | -10°C~50°C | |||
STANDARD | ||||
Compliance Safety | CE | |||
