| Type of Container | 20 Feet High Cube Open Side | 40 Feet High Cube Open Side |
| External Dimensions (L*W*H/mm) | 6058*2438*2896 | 12192*2438*2896 |
| Container Weight (Tons) | 3 | 7 |
| Solar Array Capacity (Pmax / kWp) | 99.12 | 168 |
| Total Weight (Tons) | 11.5 | 26.8 |
| Folding & Unfolding Time (Min.) | 120/80 | 240/160 |
| Unfolded Footprint (L*W*H/m) | 102.49*6*0.9 | 205*12*0.9 |
| Folded Footprint (L*W*H/m) | 6*2.34*2.9 | 12*2.34*2.9 |
| Max. Slope Limit | 1% | 1% |
| Installation Person | 6 | 12 |
| Compatibility (Option 1) | AC output with inverter | AC output with inverter |
| Compatibility (Option 2) | Lithium battery cabinet | Lithium battery cabinet |
| Orientation | Any azimuth by container | Any azimuth by container |
| Solar Panel Type | N Type i-Topcon | N Type i-Topcon |
| Solar Panel Power (Pmax / Wp) | 590W | 590W |
| Quantity of modules | 168 | 336 |
| String Inverter Capacity (Pmax / kWp) | 99.12 KWP | 168 KWP |
| Output Power Volt.Current | 220/380,230/400,3L/N/PE or 3L/PE | 220/380,230/400,3L/N/PE or 3L/PE |
| Operating temperature | -30 °C to +60 °C (-86°F to +140 F°) | -30 °C to +60 °C (-86°F to +140 F°) |
| Quantity of String inverters (sets) | 1 | 2 |
| Bracket Materials | Hot Galvanized Carbon Steel | Hot Galvanized Carbon Steel |
| Single Bracket Dimension (mm) | 4712*2433*30 | 4712*2433*30 |
| Angle of Unfolding Bracket (°) | 15~35 | 15~35 |
| Length of Unfolding Bracket (m) | 95.5 | 95.5 |
| Project area of Unfolding Bracket (m2) | 615 | 1230 |
| Connection options | on-grid and off-grid, Hybrid | on-grid and off-grid, Hybrid |
| Certification | TüV tested, CE-certified | TüV tested, CE-certified |
