MPPT Solar Charge Controller (12/24/48VDC ) | ||||||||||||||
Model: CP | 30A | 40A | 50A | 60A | 80A | |||||||||
Charging Method | Three Stages: Constant Current (MPPT), Balanced Charging, Floating Charge | |||||||||||||
Dynamic respnse recovery time | 12V/24V48V | ≤500us | ||||||||||||
Static Power | 12V/24V48V | ≤ 2w | ||||||||||||
Mechine Efficiency | 12V/24V48V | ≥ 96.5% - 99% | ||||||||||||
MPPT operating voltage range | 12V/24V48V | DC18V-150V; 34V-150V; 65V-150V | ||||||||||||
Maximum solar panel input power | 12V | 420W | 570W | 700W | 900W | 1100W | ||||||||
24V | 840W | 1130W | 1400W | 1700W | 2200W | |||||||||
48V | 1650W | 2270W | 2800W | 3400W | 4400W | |||||||||
Output Characteristics | ||||||||||||||
Current limiting Protection | 12V/24V48V | 32A | 42A | 52A | 62A | 82A | ||||||||
Input low voltage protection, input high voltage protection | ||||||||||||||
Short circuit protection | After 5 trial starts will enter the protection state, Restart Recovery | |||||||||||||
Temperature Protection | 90ºC | |||||||||||||
Temperature rise protection | Reduce Power Output when exceed 85ºC | |||||||||||||
Noise | ≤50dB | |||||||||||||
Heat Dssipation Method | Forced air cooling, Fan speed is adjusted by temperature | |||||||||||||
Humidity | 0-90%RH (No condensation) | |||||||||||||
