LITHIUM STORAGE supports offering standard battery
modules and customization of battery modules based
on LFP/NCM prismatic cells, including the structure
of the banding module and frame welding module.
The high structural strength of the frame welding
module meet harsh vehicle operating conditions,
and the high flexibility of the banding module
meets a wide range of dimension requirement.
| No. | Items | NCM102Ah STANDARD MODULE | Note |
MSXX3-22.2V102A 102Ah1P6S | |||
| 1 | Nominal voltage(V) | 22.2 | |
| 2 | min | 16.8 | |
| 3 | max | 25.8 | |
| 4 | Nominal capacity(Ah) | 102 | 25±2℃,1/3C |
| 5 | Nominal energy（KWh ） | 2.2644 | 25±2℃,1/3C |
| 6 | Available energy（KWh ） | ≥2.219 | |
| 7 | Group mode | 1P6S | |
| 8 | End of life residual capacity (Ah) | 81.6 | Residual capacity≥80% initial capacity，@25℃ |
| 9 | Module weight（kg） | 11.2±0.3 | |
| 10 | Maximum continuous charge current（A） | 102 | |
| 11 | Maximum short pulse charge current（≤10s） | 204 | |
| 12 | Maximum continuous discharge current（A） | 102 | |
| 13 | Maximum short pulse discharge current（≤10s）（A） | 306 | |
| 14 | SOC operating range（%） | 10~90 | |
| 15 | Insulation requirements(MΩ) | ≥20 | 500V DC，High voltage output to battery module shell, at the normal temperature and humidity |
| 16 | Module cooling method | Natural cooling | |
| 17 | Module heating method | No | |
| 18 | Shipping capacity (SOC) | 30%~70% | SOC is consistency in the same batch |
| 19 | Shipping consistency（mv） | ＜20 | Voltage difference between cell of module＜20mV |
Coulomb efficiency | ≥95% | ||
Module self-discharge | ≤3% | 25±2℃,50%SOC | |
| 20 | Dimension L （mm） | 355 | |
| 21 | Dimension W（mm） | 151.5 | |
| 22 | Dimension H（mm） | 108.5 |
01 02
Carton for air transportation and Meeting the UN38.3 package
plywood case for sea transportation standard for dangerous goods
Light weight
The weight of the VDA module is much lighter than similar products of the same capacity.
High performance
The VDA module has high energy density, low self-discharge, and low internal resistance, which can save the user cost.
Long lasting
Lithium-ion batteries can be charged and used multiple times. NCM102Ah 1P6S VDA?modules last longer than traditional batteries.
The NCM102Ah 1P6S VDA MODULE represents a significant advancement in energy storage technology for electric-powered mobilities. With its series and parallel connection, customizable voltage and capacity, reliability, efficiency, and sustainability, this module paves the way for the widespread adoption of electric vehicles and other electric-powered mobilities.
Invest in the NCM102Ah 1P6S VDA MODULE to unlock the full potential of electric mobility. Experience the benefits of enhanced range, reliable performance, and reduced environmental impact. Embrace this innovative energy storage solution and contribute to a sustainable and electrifying future of transportation.
