| Input (DC) | |
| Max DC Open Circuit Voltage per Input (Vdc) | 90 |
| Max DC Current per input (Adc) | 20 |
| Output (DC) | |
| Maximum Output Voltage (Vdc) | Voc * n (n=1/2/3/4) |
| System | |
| Maximum System Voltage (Vdc) | 1500 |
| Mechanics | |
| PV Cable | 12AWG |
| PV Connectors | Mc4(Contact NEP for other connectors options) |
| Size (not including PV cable) | 5.12’ x4.73’ x 1.14’ (PVG-1 5.90’ x5.71’ x 1.00’ (PVG-2, PVG-3) 10.5’ x 8.25’ x 1.25’ (PVG-4) |
| Protection Degree | NEMA 6 |
| Operating Ambient Temperature | -40°C–+85°C |
| Mounting Method | Rail, Frame (option) |
| Signal? | |
| Communications | DC Power Line Compatible with SunSpec signaling |
| Certifications | |
| Product Safety Compliance | UL 1741 CSA C22.2 No. 107.1 NEC 2014/2017 690.12 Canada CEC 2015 64-218 |
